Techstream Customization List: What is included

Thanks a lot to bigbird1 for this detailed and comprehensive list on Techstream software!

Here's the list of most of the items that are customizable:

ECO driving light indicator on/off: done through multi-information display

Language and units for the gauges and meters: done through multi-information display

Drive information (fuel consumption, units, miles (km) to empty, average speed etc etc: done through multi-information display

Unlocking using a key: driver's door in 1 step, all doors in 2 steps (default) or all doors unlocked in 1 step: Techstream only

automatic door lock: shifting out of Park (default), locking once the vehicle hits 12 mph, or turning auto locking off: done through audio system screen

automatic door unlock: shifting into park (default), when driver's door is opened, or disabling auto unlock: done through multi-information display

If you have the Smart Key system: the operational signal of the Smart key system can be changed: buzzer volume, emergency flasher acknowledgement, elapsed time before auto door lock-pen door warning buzzer can all be manipulated: done through multi-information display

With the wireless remote, you can enable or disable the wireless remote itself and change the operation of the power sliding door controls on the remote : Techstream only

If you have memory power driver's seat,you can change the way the memory position is activated: done through multi-information display

If you want to change the door linking the seat memory: Techstream only

light sensor sensitivity and elapsed time for auto headlights off: done through multi-information display

auto high beam on/off and DRL system on/off: Techstream only

intuitive park assist adjustments: done through multi-information display

AC on operation linked with AUTO button on/off: done through multi-information display

elapsed time before interior lights turn off: 15s default, off, 7.5s, 30s: done through multi-information display

6 other illumination options and seatbelt buzzer on/off: Techstream only

There are a few other options only on the LTD package that I've left out.

There is a way to find the full list:

Chapter 9-2 Customization

It's all on p. 621 of the owner's manual.

Note: for the auto headlight delay, it is adjustable, to turn the headlights off after all doors are closed, from immediately (no delay ), to 30s (default), 60s, or 90s.

you don't need Techstream to adjust this. It is done through the audio system touchscreen.

Hope this helps

Yanhua mini ACDP Connect to PC Steps

Method one: Firstly bind the Yanhua MINI ACDP device with the mobile phone, then connect with the PC version and bind the ACDP.

1、Connect the ACDP device with a cell phone first, and confirm that the connection is normal (Picture 1). That is, the ACDP device and the phone are connected to the same WIFI. Then exit the APP or untie the device in "Cell phone bound to Mini ACDP device " (Picture 2 - Picture 3), so that the ACDP device can be bound and connected by another device (PC).

2、Please connect the PC to the same WIFI as the cell phone (selected the one among the following three options)

A. If there is a WIFI access of the PC, please do not use wired network and connect the same WIFI as the cell phone.

B. If the WIFI router connected by cell phone supports both wired and WIFI network, please use wire to connect the PC with the router.

C. If there is NO WIFI access of the PC, please insert a WIFI adapter in the USB port and unplug the network wire of PC, then connect the same WIFI connected by cell phone.

3、Open the ACDP software on PC, and click "Setting"

4、Click " Bound to Mini ACDP device" on ACDP software interface.

5、Select the corresponding device ID to bind.

Method two: Connect the PC via Bluetooth adapter

1、 Plug the Bluetooth adapter into the PC USB port ( Make sure the driver is installed) and the PC is connected to WIFI.

2、Open ACDP software on the PC desktop.

3、Click on SETTING in the red box as shown in the picture.

4、Click on "Initial use settings "

5、 Press and hold the "SET" button on the ACDP device for 7 seconds until the device buzzer's sounds, then release the "SET" button and click "Next".

6、 Initial use of settings (WIFI configuration)
If the PC is a laptop with WIFI access function, read 6.1
If the PC is connected through a WIFI router with wired network, read 6.2

6.1：If the PC with WIFI access function, Connect the PC to WIFI.

If the PC without WIFI access function, Connect the WIFI adapter with the PC USB, Connect the WIFI and follow the steps shown as below.

The operation result is shown in the picture as below.

6.2：If the PC without WIFI access function, the PC is connected through a WIFI

router with wired network. Follow the steps shown as below.

The operation result is shown in the picture as below.

7、The software prompts "YanhACDP device connected to WIFI successfully", click "OK".

8、Select the corresponding device ID to bind

9、Confirm the bound device ID, click "Back".

10、Confirm that the device is successfully bound and connected.

https://www.chinacardiags.com/wholesale/yanhua-mini-acdp-programming-master.html

AURO OtoSys IM100 vs Lonsdor K518ISE: which better?

Comparison: AURO OtoSys IM100 and Lonsdor K518ISE

It's aimed to help make a purchase of decent auto key programmers for universal vehicles at a good price.

Auro im100 and Lonsdor K518ise differs in special functions and Volvo key program.

That is,

IM100 supports some special functions that K518ise has no luck.

But K518ise is able to program new keys to VOLVO while IM100 has failure.

In detail...

AURO OtoSys IM100 Special Functions Inside SERVICE:

Oil Serive Reset, Parking Brake Pad Relearn After Replacement, Steering Angle Sensor Relearn, Battery Registration and Reset, Diesel Particulate Filter Regeneration, Tire Pressure Monitoring System

The Service section is specially designed to provide you with quick access to the vehicle systems for various scheduled service and maintenance performances. The typical service operation screen is a series of menu driven executive commands. By following the on-screen instructions to select appropriate execution options, enter correct values or data, and perform necessary actions, the system will guide you through the complete performance for various service operations.

OtoSys IM100 Oil Reset Service

This function allows you to perform reset for the Engine Oil Life system, which calculates an optimal oil life change interval depending on the vehicle driving conditions and climate. The Oil Life Reminder must be reset every time the oil is changed, so the system can calculate when the next oil change is required.

OtoSys IM100 Electronic Parking Brake (EPB) Service

This function has a multitude of usages to maintain the electronic braking system safely and effectively. The applications include deactivating and activating the brake control system, assisting with brake fluid control, opening and closing brake pads, and setting brakes after disc or pad replacement, etc.

OtoSys IM100 Battery Management System (BMS) Service

The BMS allows the scan tool to evaluate the battery charge state, monitor the close-circuit current, register the battery replacement, and activate the rest state of the vehicle.

OtoSys IM100 Steering Angle Sensor (SAS) Service

Steering Angle Sensor Calibration permanently stores the current steering wheel position as the straight-ahead position in the steering angle sensor EEPROM. Therefore, the front wheels and the steering wheel must be set exactly to the straight-ahead position before calibration. In addition, the vehicle identification number is also read from the instrument cluster and stored permanently in the steering angle sensor EEPROM. On successful completion of calibration, the steering angle sensor fault memory is automatically cleared.

OtoSys IM100 Diesel Particulate Filter (DPF) Service

The DPF function allows you to carry out numerous functions to the Diesel Particulate Filter system without having to send your car to a main dealer. The tool will manage DPF regeneration, DPF component replacement teachin and DPF teach-in after replacing the engine control unit. ECM monitors driving style and selects a suitable time to employ regeneration. Cars driven a lot at idling speed and low load will attempt to regenerate earlier than cars driven more with high load and high speed. In order for regeneration to take place, a prolonged high exhaust temperature must be obtained. In the event of the car being driven in such a way that regeneration is not possible, i.e. frequent short journeys, a diagnostic trouble code will eventually be registered, DPF light and "Check Engine" indicator comes on. A service regeneration can be requested in the workshop, using the diagnostic tool.

OtoSys IM100 Tire Pressure Monitor System (TPMS) Service

This function allows you to quickly look up the tire sensor IDs from the vehicle's ECU, as well as to perform TPMS replacement and sensor test.

Reference: How to use AURO IM100 for special functions

Lonsdor K518ise VOLVO Key Programming:

Lonsdor K518ise can program new keys to VOLVO S40, S60, S80, XC60, XC90, C30, C70, V40, V60, V70

Lonsdor K518ISE Volvo car list:

Series Origin Year Fuel Type Function

S60 Other Other Other Proximity Key[insert key to start]

S60 Other Other Other Smart Key[one-button start]

S80 Other 09- Other Smart Key[one-button start]

XC60 Other 09- Other Smart Key[one-button start]

S80 Other 09- Other Proximity Key[insert key to start]

XC60 Other 09- Other Proximity Key[insert key to start]

S40 Other Other Other Smart Key

S40 Other Other Other Key Programming

S80 Other -09 Other Proximity Key[insert key to start]

V40 Other Other Other Proximity Key[insert key to start]

C30 Other Other Other Key Programming

C30 Other Other Other Smart Key

V40 Other Other Other Smart Key[one-button start]

S80 Other -09 Other Smart Key[one-button start]

V60 Other Other Other Proximity Key[insert key to start]

V60 Other Other Other Smart Key[one-button start]

XC60 Other -09 Other Proximity Key[insert key to start]

XC60 Other -09 Other Smart Key[one-button start]

XC90 Other Other Other Flip Key

C70 Other Other Other Key Programming

C70 Other Other Other Smart Key

V70 Other 09- Other Proximity Key[insert key to start]

V70 Other 09- Other Smart Key[one-button start]

Look here: How to use Lonsdor K518ISE to add VOLVO smart keys

https://blog.obd2diy.fr/2017/10/12/lonsdor-k518ise-obd-program-volvo-smart-keys/

Should I buy Auro OtoSys IM600 or Obdstar X300 DP?

MB SD C4 09.2018 DAS Update: Fault (1.2)-2.503.9901 - Solved!

Here are remedies of the following DAS error "Fault (1.2)-2.503.9901" using SD connect C4 multiplexer on Windows 7, the error started with version 2017.07 but figured upgrading to XDOS 2018.09 would have solved the issue but still occurring.

Multiplexer: SD connect C4

Operation system: Windows 7

Software: DAS

Version: DAS version 2018.07 upgrading to version 2018.09

The error: Fault (1.2)-2.503.9901

Initialization of diagnosis multiplexer failed.
Possible causes.
The link between the diagnosis multiplexer and the diagnosis socket is interrupted.
The link between the diagnosis multiplexer and the diagnosis unit is interrupted.
The voltage supply at the diagnosis socket (circuit 30 and (or) circuit 31) is faulty.
Note:
When using SDconnect check the connection status using the Toolkit.

The fault (1.2)-2.503.9901 usually happens because of:
The link between the diagnosis multiplexer and the diagnosis unit is interrupted.

Remedy:1. use a good lan cable
2. set lan tcp/ip to:
ip address: 172.29.127.119
Subnet mask: 255.255.0.0

Wirless_IP_set to C4

Lan_IP_set to C4you will see the status of connection happening in sdconnect toolkit in right bottom corner.

SOLUTION:

Solved by changing SDConnect from 21 to 04

Reference:XDOS SDconnect Configuration

To save an ad-hoc network and its network key on the guest computer (running Windows 7)

Note down the SSID, security type, encryption type and the key of the ad-hoc network. Disconnect your connection to any wireless network and switch off/disable your wireless device. Turn on/enable your wireless device but don't connect to any network. (Thanks GK.)

Click on the network icon in the taskbar.

Click Open Network and Sharing Center > Manage Wireless Networks > Add.

Click "Manually create a network profile". (This may look silly but we really are going to create an infrastructure network now.)

Enter the network name (SSID), security type, encryption type (if any) and the key that you noted in step 1.

Uncheck both checkboxes ("Start this connection automatically" and "Connect even if the network is not broadcasting".)

[Note that you cannot have the connection start automatically. If you try to have it checked, step 10 will fail. A different way to start it automatically during system boot is described below.]

Click Next > Close. Your connection must appear in the list with the icon suggesting infrastructure (two big screens connected to a tube). Don't worry about it.

Click Start, type in "cmd" in the search box, press Enter.

In the Command Prompt, type in "netsh wlan set profileparameter name=NetworkName ConnectionType=IBSS", exactly as shown, without quotes, except you must substitute NetworkName with the SSID (network name) of your ad-hoc network.

If everything went well, you'll see that the icon has now changed to an ad-hoc icon (three small screens connected to each other) in the Manage Wireless Networks window.

Turn on/enable your wireless device, and try connecting to the Ad-hoc network. You will notice that you no longer need to enter the network key.

To automatically connect to a saved ad-hoc network during Windows boot (can be applied to both guest and host computers running Windows 7)

Click Start > point to All Programs > right-click Startup > click Open. (You may choose Open All Users instead if you prefer).

Right-click an empty space and click New > Shortcut.

Type in "netsh wlan connect NetworkName". Once again, NetworkName must be substituted with the SSID of your ad-hoc network.

Click Next and enter a fancy name such as "Connect to NetworkName" or something like that.

Click Finish and you're done.

This shortcut will run when Windows starts up, giving you a very brief flash of the black command window, followed by your computer connecting to the ad-hoc network if it is available.

Tip: You can also pin the shortcut in your taskbar or copy it to the desktop to easily connect to the network any time you want. Note: You will probably need Administrator access to complete some of the steps above (in both procedures).

By Sarrukin

Where to buy RENAULT CAN CLIP clone for good quality?

Vident iLink400 VOLVO XC90 2006-2016 Diagnostics: Confirmed!

Confirmed! The customized auto diagnostic tool Vident iLink400 full system scan tool is verified to work for VOLVO XC90 the year 2006-2016:

Abilities confirmed to work well:

read ECU information: confirmed!

read and clear fault codes: confirmed!

freeze frame: confirmed!

perform active test: confirmed!

special functions: confirmed!

FYI, some functions "yes or no" depends on models.

Vident iLink400 VOLVO XC90:

Vident iLink400 reader Special Functions:

https://www.chinacardiags.com/upload/pro/vident_ilink400_full_system_volvo_function_list.xlsx

1

Readiness code

2

Adaptation of the throttle unit

3

Quick test of exhaust camshaft control

4

Quick test of intake camshaft control

5

Quick test of the fuel pump (FP)

6

Quick test of the fuel tank system (USA/CDN)

7

Programming optimizing parameters

8

Activating TEST MODE

9

Control module adaption

10

Reset adaptation to zero

11

Resetting the counter for-Gearbox oil change

12

Resetting adaptation

13

Calibration of gear position sensor

14

Resetting the oil counter

15

Calibration the system

16

Calibrating the occupant weight sensor(OWS)

17

Configuring the number of seats

18

Storing the ID number for the occupant weightsensor (OWS)

19

Activating and reading off sun roof parameters

20

Add or Remove remote controls

21

Programming the control unit

22

Configuration of the siren

23

Replacing the control module

24

Reading the programmed values

25

Quick test of the tire pressure sensor

26

Logging detailed diagnostic data

27

Reading data for vehicle configuration

28

Programming the control module, centralelectronic module(CEM)

29

Quick test of alternator fuction

30

Resetting factory settings

31

Resetting low voltage counters

32

Resetting car

33

Testing all displays and lamps in instrument

34

Programming the audible acknowledgementsignal, seat belt reminder

35

Programming the driver information module(DIM)

36

Reading off programmed values

37

Resetting the service reminder indicator(SRI)

38

Resetting the carphone code

39

Caibrating the position sensor for Bi-Xenonlamps

40

Reading off the alarm cause

41

Programming the climate control module (CCM)

42

Checking LIN bus

43

Reading off programmed parameters

44

Identifying the Damper Motor Module (DMM)

45

Programming the additional and parking heater

46

Initializing the window position

47

Programming soft stop

48

Programming the remote control setting

49

Checking current values

50

Quick test of the fuel tank system

51

Programming the control module

52

Installing/removing key

53

Read-out of programmed values in driver information module (DIM)

54

Reading off static data

55

Calibrating the Bi-Xenon lamp position sensor

56

Self-adjustment of damper motor end stops

57

Adjusting parameter, ECC

58

Read-out of programmed values in driver information module

59

Window position set-up

60

Programming the seat temperature

61

Calibration(DSTC)

62

Checking brake light switch adjustment

63

Calibration

64

Reading the user information

65

Activating/deactivating Volvo on Call

66

Volvo On Call service check

67

Reinstalling the spare battery

68

Calibrating the system

69

Add or Remove key

70

Resetting the SRL (Service Reminder Lamp) to

71

Program functionality

72

Pzerorgoramming combined instrument panel

73

Reading off programmed values in the combined instrument panel

74

Add/Erase keys

75

Erase the VIN code

76

Initiate immobilizer control module

77

Programming lock type

78

Programming new control module

79

Pragramming remote control

80

Checking the number of remote controls

81

Reading off the programmed values

82

Reading the static data

83

System test

84

Programming the ECC control module

85

Self-adjusting of shutter motor end position

86

Updating the electronic climate control module (ECC)

87

Resetting "Transmission oil replacement" counter

88

Readiness code (USA/CDN)

89

Reading off the diagnostic operating cycle

90

Programming fuel pump (FP) start diesel

91

Programming the idle speed

92

Check and adjust dynamic pump setting

93

Quick fuel tank system test

94

IUMPR read out (USA/CDN)

95

Testing the fuel pump (FP)

96

Programming the optimizing parameters

97

Adaptation of the exhaust gas recirculation (EGR) valve

98

Combustion of soot particles

99

Resetting the odometer particle trap

100

Resetting the adaptation values

101

Reading off the configuration

102

Programming of global opening/closing of windows

103

Testing all displays and lamps in the driver information module (DIM)

104

Indicates programmed values

105

Programming the infotainment control module(ICM)

106

Programming customer parameters

107

Calibration (cars with DSTC)

108

Calibration of the climate control module(CCM)

109

Programming remote control setting

110

Calibration of position sensor, GDL lamps

111

Calibration of position sensor

112

Resetting counter oil

113

Reading off VIN LEARNED

114

Programming a new control module

115

Programming the cruise control

116

Programming a new control unit

117

Positioning of accelerator pedal sensor

118

Continuous variable valve timing (CVVT) test

119

Activating the DSA warning lamp

120

Activating torque reduction

121

Modify the settings in the combined instrument panel

122

Programming the outside temperature display

123

Programming the trip computer function

124

Programming a new combined instrument panel

125

Resetting the mileage, new car

126

Resetting the service reminder lamp(SRL)

127

Calibrating the control module

128

Programming the alarm function

129

Programming the remote control function

130

Resetting the Transmission fluid change

131

Resetting the adaptation

132

Pcorougnrtaemrming the climate control module

133

Self-adjustment of damper motor end positions

134

Idling speed adjustment

135

Positioning the throttle position sensor

136

Activating self-adjustment

137

Updating the climate control module

138

Updating the combined instrument panel for diesel engines

139

Reading cause of alarms

140

Programming and calibration

141

Installing low beam reduction US/CDN

142

Programming the control module, central electronic module(CEM) US/CDN

143

Programming the combined instrument panel

144

Accumulator draining

145

Action for falling temperature and cold draught in passenger compartment

146

Activating components

147

Activating components and functions

148

Activating components/functions

149

Activating fuel pump in tank

150

Activating gear indication

151

Activating heating coil, FSM

152

Activating line pressure solenoid STH

153

Activating steering wheel heating

154

Activating the internal test procedures

155

Activating turbo control valve

156

Activating turbo control valve (VNT-regulator)

157

Activating wipers, front/rear

158

Activating/reading out components/functions

159

Activation

160

Activation and service

161

Activation brake vacuum pump

162

Activation of adaption

163

Activation of blower fan run-on

164

Activation of boot lid opening/closing

165

Activation of installation image

166

Activation of quick-lock motors.

167

Activation of the indicator for visual collision warning

168

Activation/pre-activation of Volvo On Call

169

Adaptation of differential pressure sensor particle filter

170

Adaptation of fuel pressure control valve

171

Adaptation of heated oxygen sensor

172

Adaptation of mass airflow sensor

173

Adaptation of neutral position sensor

174

Adaptation of swivel channel throttle

175

Adaptation of throttle module

176

Adaptation of turbo control motor

177

Adaption of camshafts

178

Adaption of oil level sensor

179

Adaption reset, control valve inlet (throttle)

180

Adaption turbo system

181

Add / erase keys

182

Adding/Erasing keys

183

Adjusting calculated oil level

184

Adjusting calculated oil level/oil quality

185

Adjusting parameters, ECC

186

Adjustment of deflection limit on steering

187

Airflow setting in rear passenger compartment

188

Ageuatormatic battery test

189

Bleeding the oil pressure pump

190

Calibrate all sensors, Y2 BCM

191

Calibrating internal sensors, BCM

192

Calibrating the climate control module (CCM)

193

Calibrating the exhaust gas recirculation (EGR) valve

194

Calibrating the inertial measurement unit (IMU)

195

Calibrating the occupant weight sensor (OWS)

196

Calibrating the position sensor for Bi-Xenon

197

Calibration (DSTC)

198

Claalmipbsration (only vehicles with DSTC)

199

Calibration angle sensor

200

Calibration of differential electronic module (DEM)

201

Calibration of electric rear axle drive module (IEM)

202

Calibration of high voltage generator module (IGM)

203

Calibration of iTPMS

204

Calibration of radar and camera

205

Calibration of side obstacle detection control module left (SODL)/Right (SODR)

206

Calibration, entry position

207

Camera activation, parking aid camera

208

Central lock motors, activating

209

Change volume on LDW

210

Check of the owner's manual in the vehicle

211

Check the communication with the remote control receiver.

212

Check whether PHM has Volvo On Call

213

Checking ABL function

214

Checking active grill shutter

215

Checking all antennas

216

Checking and adjusting calculated ethanol content

217

Checking and adjusting hard and jerky shifts

218

Checking and resetting the adaption for

219

Checking AUX-panel

220

Cihnejceckitnogr scommunication and control module

221

Checking current soot quantity and combustion of soot in particle filter

222

Checking door handles

223

Checking headphone socket.

224

Checking injectors

225

Checking installation, brake light switch, and brake pedal position switch

226

Checking loudspeaker element

227

Checking loudspeakers

228

Checking MOST communication

229

Checking noise from optional equipment.

230

Checking seatbelt-related components at

231

Checking the Active Noise Control (ANC)

232

Cchoelclikisingo nthe additive level

233

Checking the DC/AC converter

234

Checking the engine oil level

235

Checking the Four-C (Continuously Controlled Chassis Concept) keypad unit

236

Checking the fuel pump (FP)

237

Checking the navigation's hard disk

238

Checking the oil level

239

Checking the PAD-light

240

Checking the window in the rear door

241

Checking USB port, infotainment head unit (IHU)

242

Checking video signal (only applies vehicles with Infotainment control module, ICM)

243

Combustion of soot in the particle filter

244

Combustion of soot particles, particle trap

245

Communication on MOST

246

Compartment fan afterblow

247

Compartment fan afterblow, status

248

Control module adaptation

249

Control module, calibration

250

Cooling of the cooling system

251

Deactivation/activation of engine remote start ERS

252

Deleting phone book

253

Display of DSTC/ESC message

254

Display of oil check

255

Display of vehicle speed.

256

Ejection of key

257

Entering the engine oil level after service

258

ETM test

259

Extended diagnostic trouble code (DTC) reading

260

Extended fault-tracing for the diagnostic trouble code (DTC), Engine control module

261

Filling and bleeding the cooling system

262

Filling of fuel system auxiliary heater

263

Finding the predefined service position

264

Fuel pump activation for vehicles without fuel pump module (PEM)

265

Fuel tank system quick test

266

Identification of the heater

267

Identifying components on the LIN network that belong to the climate control system (CCM)

268

Ignition switch key position.

269

Initial adaptation

270

Initializing the front seat position

271

Initializing the window in the front door

272

Initializing the window in the rear door

273

Initiate the immobilizer control module

274

Initiating the sun blind

275

Initiation of tailgate's position

276

Initiation of tailgate's position, Power operated tailgate module (POT)

277

Initiation of the TCS switch by the tunnel console

278

Insulation measurement

279

Loading assistance adjustment

280

Manual battery test

281

OBC LED test

282

OBC Lock test

283

Open circuit on MOST-cable (only vehicles with Infotainment control module (ICM))

284

Open-circuit in the MOST cable.

285

Operating and initiating the roof hatch

286

Parking camera, activating (V40/V40 Cross Country; S60/V60/XC60 structure week 13w46-)

287

Parking camera, setting (V40/V40 Cross Country; S60/V60/XC60 structure week 13w46-)

288

Position sensor xenon lamp

289

Powering the Pedestrian Airbag system

290

Powering the SRS system

291

Pre-delivery service for new car

292

Programming and calibrating the convertible

293

Programming and reading off the programmed system values

294

Programming control module

295

Programming cruise control

296

Programming LEDs for central locking system

297

Programming loudest audible signal, seat belt reminder

298

Programming of cruise control

299

Programming of parking assistance module (PAM)

300

Programming of rear window wiper when

301

Programming of short flash sequence

302

Prerovegrrasimmnging other settings.

303

Programming parameters / functions

304

Programming parameters/functions

305

Programming remote control

306

Programming safety lighting.

307

Programming seatbelt reminder in backseat

308

Programming seatbelt reminder in front seat

309

Programming text message, seatbelt reminder

310

Programming the clock

311

Programming the cruise control

312

Programming the driver information module (DIM)

313

Programming the evaporator, climate control module (CCM)

314

Programming the gear shift indicator

315

Programming the HCM switch function

316

Programming the infotainment control module (ICM)

317

Programming the remote control

318

Programming the seat memory's delay time and acknowledgement

319

Programming the seat temperature (CEM)

320

Quick test of alternator function

321

Quick test of fuel tank system (USA/CDN)

322

Quick test of the function of the additional/parking heater

323

Quick-test injectors

324

Quick-test of EVAP-valve

325

Quick-test of HCM

326

Read out of the number of programmed remote keys.

327

Read out the stored ID numbers for the tyre pressure sensors.

328

Read-out and resetting alco-lock

329

Read-out of causes of 10 latest occurrences of blocked autostop of engine

330

Read-out of fuel volume.

331

Read-out of number of occurrences of blocked autostop of engine

332

Read-out of part number and serial number,Remote Keyless Entry (RKE)

333

Read-out of part number for Remote Receiver Module (RRX) and siren (SCM)

334

Reading alarm causes

335

Reading off alarm cause

336

Reading off alarm causes

337

Reading off and programming vehicle mode

338

Reading off blocks of diagnostic trouble codes (DTCs)

339

Reading off diagnostic data

340

Reading off IUMPR (USA/CDN)

341

Reading off power supply position

342

Reading off the configuration, MOST

343

Reading off the programmed parameters in the climate control module (CCM)

344

Reading off the result from a ring break diagnostic

345

Reading out detected/expected control modules/sensors

346

Reading out electronic damper motor, actual/preset range and tolerance limit

347

Reading out permanent diagnostic trouble codes (USA/CDN)

348

Reading VIN LEARNED

349

Reading-out programmed parameters in the climate control module

350

Readout of causes for the 10 latest occasions of blocked combustion engine operation

351

Readout of causes for the 10 latest occasions of blocked stop of combustion engine operation

352

Readout of causes for the 10 latest occasions of system requested combustion engine

353

Readout of current from battery monitoring sensor

354

Readout of information stand-by current

355

Readout of number of blocked combustion engine operations

356

Readout of number of blocked stops of combustion engine operations

357

Readout of number of occurrences of system requested autostart of engine

358

Readout of number of system requested combustion engine operations

359

Readout off

360

Rear view mirror light sensitivity.

361

Refilling the feed hose with additive

362

Reinstalling the reserve battery

363

Remote control

364

Remote controlled immobilising, cause

365

Remote controlled immobilising, status

366

Request for self-test.

367

RESET VOC BATTERY P2 PHM

368

Resetting adaptation for the compressor bypass valve

369

Resetting adaptations and wear counter for supercharger

370

Resetting adaptations for air flow measurement

371

Resetting adaptations for camshaft regulation exhaust

372

Resetting adaptations for camshaft regulation,intake

373

Resetting adaptations for cylinder balancing

374

Resetting adaptations for front heated oxygen sensor

375

Resetting adaptations for fuel flow regulation valve

376

Resetting adaptations for fuel/air mix (fueltrim)

377

Resetting adaptations for rear heated oxygen sensor

378

Resetting adaptations for rear heated oxygen sensor regulation

379

Resetting adaptations for swirl damper

380

Resetting adaptations for the diesel particle filter

381

Resetting adaptations for the EGR valve

382

Resetting adaptations for the fuel pump, low pressure side

383

Resetting adaptations for the fuel system (high pressure side)

384

Resetting adaptations for the injectors

385

Resetting adaptations for the particle filter's differential pressure sensor

386

Resetting adaptations for the throttle

387

Resetting adaptations for turbocharger control

388

Resetting counter by-passing alcolock.

389

Resetting counter for fuel ageing

390

Resetting counter for oil quality

391

Resetting counter for running time, water pump

392

Resetting counter for soot amount in diesel particulate filter

393

Resetting counter particle filter

394

Resetting crash mode

395

Resetting fuel trim for control module preheating and the glow plugs

396

Resetting information about current consumption

397

Resetting side obstacle detection control module left (SODL)/Right (SODR)

398

Resetting the "Transmission fluid change" counter

399

Resetting the camshaft adaption values

400

Resetting the clutch pedal counter

401

Resetting the counter for the particle filter

402

Resetting the counter for Transmission oil,

403

Resetting the factory settings

404

Rcehasengteting the flywheel adaptions

405

Resetting the fuel adaption values

406

Resetting the information to zero on power supply when replacing the battery

407

Resetting the information to zero on power supply when replacing the battery monitoring

408

Resetting the learned maximum opening angle

409

Resetting the odometer setting

410

Resetting the oil quality counter

411

Resetting the Service reminder indicator (SRI)

412

Resetting the service reminder lamp (SRL)

413

Resetting the tank level gauge

414

Resetting transmission fluid change counter

415

Resetting transmission oil replacement counter

416

Restart of the brake control module (BCM)

417

Restart the convertible roof module (CRM)

418

Restoring supplemental restraint system

419

Self-adjustment of the shutter motor end position

420

Service calibration, parking aid camera

421

Service check forVolvo On Call

422

Set lighting on buttons to Volvo On Call

423

Setting clock deviation

424

Setting day and night mode for the

425

Start calibration of ecu

426

Tiensstt roufm efntuaelt ifolnow regulation valve

427

Test of fuel pressure regulation, high pressure side

428

Test of fuel pressure regulation, low pressure side

429

Test of internal memory

430

Test/movement of camshaft control, exhaust

431

Test/movement of camshaft control, intake

432

Testing all indicators and lamps in the driver information module (DIM)

433

Testing all needles and lamps in the dashboard

434

Testing oil pressure control

435

Testing the fuel pressure control valve

436

Unlocking catches

437

Updating the ECC control module

438

Valve activation, shut-off unit BCM

439

Workshop test (TPMS)

Vident: https://www.videntshop.com/

Vxdiag Subaru SSM3 Review

How to use Vident iLink400 for I/M readiness status data read

Look here: Vident iLink400 for newbies: guides to read I/M readiness status data

Why do you need to read I/M readiness status data?

Because I/M Readiness Status Data I/M Readiness option allows you to view a snapshot of the operations for the emission system on OBDII/EOBD vehicles.

What is I/M readiness?

I/M Readiness is a useful function used to check if all monitors are OK or N/A. The vehicle's computer performs tests on the emission system during normal driving conditions. After a specific amount of drive time (each monitor has specific driving conditions and time required), the computer's monitors decide if the vehicles emission system is working correctly.

When the monitor's status is:

OK - vehicle was driven enough to complete the monitor.

INC (Incomplete) - vehicle was not driven enough to complete the monitor.

N/A (Not Applicable) - vehicle does not support that monitor.

There are two types of I/M Readiness tests:

Since DTCs Cleared - shows status of the monitors since the DTCs were last cleared.

This Drive Cycle - shows status of monitors since the start of the current drive cycle.

How to use Vident iLink400 code reader to retrieve I/M readiness status data:

Look here: abbreviations and names of OBD II monitors supported by the Vident code reader.

There are two ways to retrieve I/M Readiness Status data:

One-click I/M readiness key

Typical way: select I/M Readiness from Diagnostic Menu

To retrieve I/M Readiness Status data by one-click I/M readiness key:

1. Press the One-Click I/M Readiness Key on the keypad and the following screen displays

1. Colored LED and build-in beeper provide both visual and audible reminders for emission check and DTCs. Below is the interpretation of the LED and build-in beeper.

When the LED is :

Green:

Indicates that engine systems are "OK" and working properly (the number of Monitors equipped with the vehicle which have run and performed their self-diagnostic testing is in the allowed range. MIL is off. ).No stored and pending DTCs exist. The vehicle is ready for an Emissions Test.

Yellow:

The tool finds a possible problem. It indicates the following two conditions:

(1) Pending DTCs exist. Please check the I/M Readiness test result screen and use the Read Codes function to view detailed codes information.

(2) Some of the vehicle's emission monitors have not working properly. If the I/M Readiness screen shows no DTC (including pending DTC), but the Yellow LED is still illuminated, it indicate a "Monitor Has Not Run" status.

Red- Indicates some problems exist with one or more of the vehicle's system, and the vehicle is not ready for an Emissions Test. As well there are DTCs found. The MIL lamp on the vehicle's instrument panel will light steady. The problem that is causing the illumination of Red LED should be fixed before an Emissions Test or driving the vehicle further.

The built-in beeper works with the colored LED simultaneous, as an assistance to reflect the I/M Readiness test results:

Green: two long beeps.

Yellow: short, long, short beeps.

Red: four short beeps.

To retrieve I/M Readiness Status data :

1.Scroll with UP/DOWN key to highlight I/M Readiness from Diagnostic Menu and press the OK key. If vehicle supports both types of monitors, a screen for monitor type selection displays. Select a monitor type and press the OK key.

2.If the vehicle is tested supports both types of monitors, following screen displays.

3.Depending on readiness test, one of these 2 screens will be present. Use the up and down arrow keys to scroll through data. Press the ESC key to exit.

or

Vident iLink400 User Manual: https://www.chinacardiags.com/wholesale/vident-ilink400-full-system.html

Edit by https://www.chinacardiags.com/ :How to use Vident iLink400 for I/M readiness status data read

Where to buy a good Nexiq USB Link 2 at a decent price?

Look here: Nexiq USB Link 2 genuine/clone price, where to buy, bluetooth setup, troubleshooting, compatible application, car list, user manual, etc

What is Nexiq USB Link 2:

It's the second generation of Nexiq USB Link for truck troubleshooting.

Nexiq USB Link 2 pcb:

Source: https://www.chinacardiags.com/wholesale/nexiq-2-usb-link-software-diesel-truck-interface-with-all-installers-33696.html

Nexiq USB Link 2 for sale:

There are many Nexiq USB Link 2 for sale on the market, some genuine and some clone.

And for most of you, you may go to Nexiq USB Link 2 amazon and Nexiq USB Link 2 ebay as usual. But actually, it's not a good option to have diagnostic tools there because you hardly ever get professional tech support of diagnosis after sale. Go to a site with experts there like https://www.chinacardiags.com/

Nexiq USB Link 2 genuine vs clone:

Look here:

https://blog.diesellaptops.com/2017/07/26/how-to-spot-a-chine-nexiq-usb-link-2-clone/

Nexiq USB Link 2 price:

The original should be 700 usd and even more. Definitely the original is the best option for trucks troubleshooting. But if you have a budget limit, try to have a good Nexiq USB Link 2 china clone at a decent price: usually less than 200 usd

Nexiq USB Link 2 bluetooth setup:

Get tech support after sale via chinacardiags.com

Note that Nexiq USB Link 2 wifi is not available for the clone.

For the different between Nexiq USB Link 2 bluetooth and Nexiq USB Link 2 wifi, look here:

https://blog.chinacardiags.com/which-to-choosenexiq-1-or-2-wifi-or-bluetooth/

Nexiq USB Link 2 troubleshooting:

Class 1 Bluetooth provides up to 100 feet of wireless freedom

Flexible configuration supports wired or wireless connectivity

Compatible with applications that diagnose engines, transmissions, ABS, instrument panels and more

Reduce reprogramming times with direct USB connection

Mixed fleet capabilities with broad protocol support

Quick access to vehicle data for maintenance or management reports

Quickly attaches to vehicle's diagnostic connector

No messy cables to untangle or get in the way with Bluetooth

Easy portability increases flexibility

May be used with desktop PC or laptop

Nexiq USB Link 2 compatible application:

Detroit Diesel Diagnostic Link

CAT Electronic Technician (On-Highway only)

Cummins Insite

International - ServiceMAXX Fleet Pro

Hino eXplorer

Volvo PTT (Premium Tech Tool)

VCAD Elite Mack/Volvo

V-MAC Service Tools

Allison DOC® For PC-Service Tool - Protocols Supported: J1939, J1708/J1587, and J1850

Allison DOC® For Fleets (1000/2000) - Protocols Supported: J1939, J1850

Allison DOC® For Fleets (3000/4000) - Protocols Supported: J1939, J1708/J1587

Eaton ServiceRanger

Bendix ACom

WABCO Toolbox

Freightliner ServiceLink

International ABS

International DLB

International Intune

International IPC v2.02

Pocketfleet Software (PF-Diagnose)

Nexiq USB Link 2 clone application confirmed:

* Allison (Included!)

* Bendix 6.3.8.0 (Included!)

* Detroit Diesel DDDL 7.05 ((Included!)

* Detroit Diesel DDCT (Included!)

* Detroit Diesel Calibration Tool (Included!)

* Eaton Service Ranger 3.2 (Included!)

* International DLB (Included!)

* International ICAP, IPTS, NETS, IPC (Included!)

* International Master Diagnostic (Incluided!)

* Meritor and Wabco Diagnostics (Included!)

* Cummins Insite 7.5 (Included!)

* Hino 2.0.2. (Included!)

* Caterpillar 2.0.1.0 (Included!)

* Perkins EST 2010B (Included!)

* V Macks 2.6.12 (Included!)

* V Macks Dealer Pro (Included!)

* Volvo VCADS 2.35.10 (Included!)

* Toyota Techstream for car (Included!)

Nexiq USB Link 2 car list:

1. VOLVO TRUCK:FM10, NH565, FH12, FM12, VHD, FH16, FM7, VN, WC, WG, WI, FH565, NH12, FL6, FL7, FL10, FL12, NH525, WX, COMP04, FE, VHD, FH, FM, VM, FM9, F10, F12 , F16, NL10, NL12,VOLVO BUSES: B10B, B10M, B10L, B10R, M10R, B12, B58, B6, B7R, OLYMPIAN, SUPEROLY
2. VOLVO BUS: B12B,B12M,B12R,B6R,B7L,B7R,B9L,B9R,B9S,B9TL,PREVH,PREVX,
3. MACK TRUCKS: V-MAC I, V-MAC II, V-MAC III, V-MAC IV, Service Diagnostic
4. VOLVO CONSTRUCTION EQUIPMENT (CE):

Wheel loader: L110E, L110F, L120E, L120F, L150E, L150F, L180E, L180F, L220E, L220F, L330E, L350F, L60E, L60F, L70E, L70F, L90E, L90F

Articulated Hauler: A25D, A25E, A30D, A30E, A35D, A35E, A40D, A40E, T450D,

Excavator: EC135B, EC140B, EC140C, EC160B, EC160C, EC180B, EC180C, EC210B, EC210C, EC235C, EC240B, EC240C, EC290B, EC290C, EC330B, EC330C, EC360B,EC360C, EC460B, EC460C, EC700C, EC700B, EC700C, ECR145C, ECR235C, ECR305C, EW140B, EW140C, EW145B, EW145C, EW160B, EW160C, EW180B, EW180C, EW200B,EW210C, FC2121C, FC2421C, FC2924C, FC3329C, PL4611

Grader: G710B, G720B, G726B, G730B, G740B, G746B, G780B, G930, G940, G946, G960 , G970, G976, G990

1. Navistar: ALL Diamond Logic Builder (DLB) ServiceMaxx
2. International: ALL Intune, MD32,
3. Freightliner: ALL ServiceLink:cascadia,century,columbia,Coronado,classic,FLDSD,4900FA, 4900SA,4900EX.
4. HINO: ENGINE:300SERIES, 500 SERIES, CR03_J08E, CR03_J05D, COMMONRAIL(J05E), J05D_US, J08E_US,P11C,VCS, Hibrid, Inverter, Brake(ABS), AT_45043LE
5. ISUZU_GMC: 1996-1999 NPR Diesel and F Series Include NPR/W 3500, NPR HD/W 4500, This is for 6.0L V-8 Gasoline Engines only, 7.8L 6HK1 Engine

Isuzu: NPR, NPR HD, NQR, NRR, FTR, FVR, FXR with 6HK1 LG4 Engine, NPR, NPR HD,NQR, NRR with 5.2L (4HK1) or 3.0L (4JJ1) Diesel engine. 6.0L V-8 Gasoline Engine

GM: W3500, W4500, W5500, WT5500, W5500 HD,with 5.2L Diesel Engine Only,T6500,T7500, T8500

Nexiq USB Link 2 user manual:

https://www.chinacardiags.com/wholesale/nexiq-2-usb-link-software-diesel-truck-interface-with-all-installers-33696.html

Edit by https://www.chinacardiags.com/

: Where to buy a good Nexiq USB Link 2 at a decent price?

Vident Diagnostic Pad: iAuto 700 vs. iAuto 710

Look here: 2018 new diagnostic pad from Vident iAuto 700 and iAuto 710

Product iAuto700 iAuto710
Screen 4.3" FTF colorful screen 4.3" FTF colorful screen
Free update for 3 years √ √
Language English, Spanish, German, French, Portuguese, Dutch, Swedish, Italian, Simplified Chinese, Traditional Chinese, Russian, Japanese, Korean, Polish, Hungarian and Thai English, Spanish, German, French, Portuguese, Dutch, Swedish, Italian, Simplified Chinese, Traditional Chinese, Russian, Japanese, Korean, Polish, Hungarian and Thai
Works on almost all electronic systems √ √
OBDI and OBDII compatibility √ √
Reads and clear codes √ √
Reads/records/graphs live sensor data √ √
Freeze frame data √ √
ECU information √ √
Multilingual menu and codes √ √
Code troubleshooters √ √
Hot keys for quick access of data √ √
EPB Service √ √
Oil Light Reset √ √
DPF Reset √
Battery Configuration √ √
ABS&SRS Service
SAS(Steering Angle Sensor Calibration) √
TPS/TBA(Throttle Body Alignment) √
Bi-directional control tests
Control module coding
Other Service &Maintenance

Vident iAuto 700 Car List:

General Diagnosis:

Chrysler, Ford, GM, Brazilian GM(For Brazilian Market Only), Au Ford (For Australian Market Only), Acura, Daewoo, Honda, Holden (For Australian Market Only), Hyundai, Infiniti, Isuzu, Kia, Lexus, Mazda, Mahindra, Mitsubishi, Nissan, Perodua, Proton, Scion, Subaru, Suzuki, Ssangyong, Tata, Toyota, Abarth, Alfa-Romeo, Aston Martin, Audi, Bentley, BMW, Bugatti, Citroen, Dacia, Fiat, Ferrari, EU Ford, Jaguar, Land Rover, Lancia, Lamborghini, Maserati, Maybach, Mercedes Benz, Mini, Opel, Porsche, Peugeot, Renault，Rolls-Royce, Saab, Seat, Skoda, Smart, Sprinter, Vauxhall, Volvo, Volkswagen, VW_CV, BRILLIANCE, BYD, CHANGAN, CHANGHEAUTO, CHERY, CHERY_NE, EMGRAND, ENGLON, FOTON, GEELY, GLEAGLE, GREATWALL, KARRY, LIFAN, MAPLE, RELY,RIICH

Oil Light Reset:

Acura, Abarth, Alfa Romeo, Audi, Aston Martin, BMW, Bentley, Bugatti, Citroen, Chrysler, Dacia, Ferrari, Fiat, Ford, GM, Holden, Honda, Hyundai, Infiniti, Isuzu, Jaguar, Kia, Lancia, Lexus, Land Rover, Mercedes Benz, Mini, Mazda, Maserati, Mitsubishi, Nissan, Opel, Peugeot, Porsche, Renault, Rolls-Royce, Saab, Seat, Skoda, Scion, Subaru, Suzuki, Smart, Sprinter, Toyota, Vauxhall, Volkswagen, Volvo

EPB Service:

Acura, Abarth, Audi, Alfa Romeo, BMW, Bentley, Bugatti, Citroen, Daewoo, EU Ford, Ford, Fait, Ferrari, GM, Honda, Hyundai, Jaguar, Kia, Land Rover, Lancia, Lexus, Maserati, Maybach, Mercedes Benz, Mini, Opel, Peugeot, Porsche, Roewe, Renault, Rolls Royce, Saab, Scion, Seat, Skoda, Toyota, Vauxhall, Volkswagen, Volvo

Battery Configuration:

Audi, BMW, Citroen, Ford, Infiniti, Jaguar, Land Rover, Lexus, Mini, Mitsubishi, Nissan, Peugeot, Seat, Skoda, Toyota, Volvo, VW

Vident iAuto 710 Car List:

General Diagnosis:

Chrysler, Ford, GM, Brazilian GM(For Brazilian Market Only)

Au Ford (For Australian Market Only), Acura, Daewoo, Honda, Holden (For Australian Market Only), Hyundai, Infiniti, Isuzu, Kia, Lexus, Mazda, Mahindra, Mitsubishi, Nissan, Perodua, Proton, Scion, Subaru, Suzuki, Ssangyong, Tata, Toyota, Abarth, Alfa-Romeo, Aston Martin, Audi, Bentley, BMW, Bugatti, Citroen, Dacia, Fiat, Ferrari, EU Ford, Jaguar, Land Rover, Lancia, Lamborghini, Maserati, Maybach, Mercedes Benz, Mini, Opel, Porsche, Peugeot, Renault，Rolls-Royce, Saab, Seat, Skoda, Smart, Sprinter, Vauxhall, Volvo, Volkswagen, VW_CV

BRILLIANCE, BYD, CHANGAN, CHANGHEAUTO, CHERY, CHERY_NE, EMGRAND, ENGLON, FOTON, GEELY, GLEAGLE, GREATWALL, KARRY, LIFAN, MAPLE, RELY,RIICH

Oil Light Reset:

Acura, Abarth, Alfa Romeo, Audi, Aston Martin, BMW, Bentley, Bugatti, Citroen, Chrysler, Dacia, Ferrari, Fiat, Ford, GM, Holden, Honda, Hyundai, Infiniti, Isuzu, Jaguar, Kia, Lancia, Lexus, Land Rover, Mercedes Benz, Mini, Mazda, Maserati, Mitsubishi, Nissan, Opel, Peugeot, Porsche, Renault, Rolls-Royce, Saab, Seat, Skoda, Scion, Subaru, Suzuki, Smart, Sprinter, Toyota, Vauxhall, Volkswagen, Volvo

EPB Service:

Acura, Abarth, Audi, Alfa Romeo, BMW, Bentley, Bugatti, Citroen, Daewoo, EU Ford, Ford, Fait, Ferrari, GM, Honda, Hyundai, Jaguar, Kia, Land Rover, Lancia, Lexus, Maserati, Maybach, Mercedes Benz, Mini, Opel, Peugeot, Porsche, Roewe, Renault, Rolls Royce, Saab, Scion, Seat, Skoda, Toyota, Vauxhall, Volkswagen, Volvo

Battery Configuration Coverage: Audi, BMW, Citroen, Ford, Infiniti, Jaguar, Land Rover, Lexus, Mini, Mitsubishi, Nissan, Peugeot, Seat, Skoda, Toyota, Volvo, VW

DPF:

Acura, Alfa Romeo, Audi, Bentley, Bugatti, Mercedes Benz, BMW, Chrysler, Citroen, Dacia, Fiat, GM, Honda, Hyundai, Infiniti, Kia, Jaguar, Lancia, Lamborghini, Land Rover, Lexus, Maserati, Maybach, Mini, Mitsubishi, Nissan, Opel, Peugeot, Renault, Rolls-Royce, SsangYong, Scion, Seat, Skoda, Sprinter, Subaru, Toyota, Vauxhall, Volkswagen, VW_CV

TBA/TPS(Throttle Body Alignment):

Acura, Audi, BMW, Citroen, Daewoo, Ford, Geely, GM, Honda, Hyundai, Infiniti, Kia, Land Rover, Lexus, Lincoln, Mitsubishi, Nissan, Opel, Peugeot, Porsche, Saab, Seat, Skoda, Toyota, VW

BYD, Brilliance, Changan, Chery, Dpfv, Geely, Greatwall, Hnmazda, Huizhong, JAC, Lifan, MG, Qnlotus, Roewe, Spark, Wuling, Zzmazda, Zznissan

Steering Angle Sensor Calibration:

Acura, Abarth, Alfa Romeo, Audi, Bentley, Mercedes Benz, BMW, Bugatti, Chrysler, Citroen, Dacia, Fiat, GM, Honda, Holden, Hyundai, Infiniti, Jaguar, Kia, Lamborghini, Lancia, Land Rover, Lexus, Maserati, Maybach, Mini, Mitsubishi, Nissan, Opel, Peugeot, Renault, Rolls-Royce, Scion, Seat, Skoda, Sprinter, SsangYong, Subaru, Suzuki, Toyota, Vauxhall, Volkswagen

Cummins Insite PRO and LITE Version - What's Different?

Cummins Insite 8 Pro Version:

https://www.obd2diy.fr/wholesale/cummins-insite-software-pro-version-for-diagnose-function-with-500-times.html

Cummins Insite 8 Lite Version:

https://www.obd2diy.fr/wholesale/cummins-insite-software-lite-version-for-diagnose-function-with-200-times.html

Cummins Insite Lite vs. Cummins Insite Pro

FUNCTIONALITY LEVEL

Cummins INSITE LITE

Cummins INSITE PRO
Features No Calibration Download Full Functionality
View Trip Information √ √
View Fault Trees √ √
Fault Information System √ √
View Troubleshooting Steps √ √
View Parameter Settings √ √
View Wiring Diagrams √ √
View Engine Dataplate √ √
Driver Rewards √ √
Data Monitor/Logger √ √
Reset Trip Information √ √
Reset and Clear Fault Codes √ √
Set Engine Features (on/off) √ √
Set/Adjust Parameters √ √
Set/Change ECM Passwords √ √
Create Settings Templates √ √
Create Work Orders/Jobs √ √
ZAP-It Functionality √ √
Run Special Features √ √
Run Diagnostic Tests √ √
Read/Retrieve Calibration Files √
Load Engine and Programable Datalink Device Calibrations √

How to use VVDI MB Tool Program Benz W209 Key?

VVDI Benz can support all key lost W164,W216,W166,W209,W211,W212,W246,W212(old),W204, W207 etc, online calculation key password.Here is the simple steps about VVDI MB BGA Tool program benz w209 with working key.

1.Read EIS data via IR way.

Choose EIS Tool,and mode,IR way,chassis.Then click read eis data and password.

Insert IR adapter to car,take out and insert again if already inserted.

You can try to read key password via IR,if failed,please use password calculation to get key password online.

2.Get Key Password.

Get directly via IR failed,then use password calculation.

Data acquisition.Insert working key to EIS.

Insert working key to device IR reader before press OK.

Save Data.

Upload data and get key password.

3.Copy password and paste in EIS data and save it.

Click EIS Tools and then click read EIS data and password.

Paste key password.

Save EIS data.

4.Prepare key file.

Load EIS data.

Then click prepare key file,please choose the key version before load and prepare.

Save Key File.

5.Write new key.

Load key file and add new key.

6.Write successfully,then test your new key.

Edit by Xhorse VVDI:How to use VVDI MB Tool Program Benz W209 Key?

Scania VCI2 VCI3 SDP3 2.32 Win7/8/10 download: 100% tested

Scania sdp3 update! Free download Scania SDP3 2.32 software crack:

https://mega.nz/#!n0xnTCrb!CjXG5od-HJSQy-XsdPY0_IrvqRodgvIfRkcGawPgvzI

scania sdp3 download->scania sdp3 activation

Windows 7/8/10

SDP3 2.32 system requirement:

Windows 7 32 bit, Windows 8/8.1 32 bit, Windows 10 32 bit....ALL OK

• Microsoft .Net Framework 4.6.2 must be installed.
  • There is no longer support for Windows 7 32 bit. For more information, see Ti 00-17 01 25.

SDP3 2.32 language: German, English,Spanish, Finnish, French, Italian,Japanese, Korean, Dutch, Polish, Arabic, Portuguese, Russian, Swedish,Turkish, Chinese, Traditional Chinese,Romanian

Scania diagnostic equipment:

Scania VCI2... works good with SDP3 2.32

Scania VCI3... 100% tested & works good with SDP3 2.32

Scania SDP3 2.32 car list:

P, G, R, and S series (2016-)

P, G, R and T series (2003-)

F, K and N series

as well as the following engines:

P96

E2011

Note: the new SDP3 2.32 covers trucks the 2017 year.

How to install Scania SDP3 2.32 software:

• Install Adobe Reader 9
  Insert SDP3 2.32 DVD software into computer
  Open Computer
  Open DVD Drive (E:) Scania 2.32

Open "AdeRdr920-en-US" to install Adobe Reader 9.2

Click on "Next"

Click on "Install"

Click on "Finish" if installation completed

2)Install NET Framework

Install ".NET Framework4.5.1" setup

Accept license agreement

Click on "Install"

Click on "Finish" when framework is well installed

3)Install SDP 2.32 setup

Copy and paste "SDP3 2.32" zip file to desktop

Extract the "SDP3 2.32" rar. File

Open the "SDP3 2.32.0.268" application on the folder

Click on "Next"

Accept license agreement

Click on "Install"

Click on "Next"

Make sure that the VCI unit and the SDP3 USB key are disconnected from the computer before continuing installation. Click on "OK"

SDP 2.32 setup completed. Click on "Finish"

4)Copy SDP3 patch

Open "replace patch" folder

Copy and replace all the SDP3 DLL files in the folder on "C:/Program Files/Scania/SDP3"

Follow this way: Right Click on SDP3 on desktop>> "Properties">>Click on "Open File Location">> "Paste" >> "Copy and replace"

• Install SDP3 Patch
  Open "Scania patch" on Scania VCI 2.32 DVD

Click on "OK" to accept warning message

Enter Unique ID and License in the windows next

NOTE: Please email your dealer to get activation ID. The supplier will calculate the activation code

Click on "patch" button

Patch success!!!

• Connect SDP3 VCI2
  Connect Scania VCI unit with computer
  Wait the system to detect Scania VCI2 hardware driver
  Open My Computer>>Device Manager>> CAN Hardware (Kvaser)>>Scania VCI2 to check well communication is built
• Run & configure SDP3 2.32 software
  Open SDP3 software on desktop

Click on "Yes" to accept system warning message

Exit SDP3 software

Open "SDP3 Configurator" software on desktop

Select "Language" tab, select software language you need from the list

Click on "Ok" to save language setting

Run SDP3 software and perform diagnostic functions.

Software installation completes

In details...

https://www.chinacardiags.com/wholesale/newest-scania-vci-2-sdp3-software-for-trucks-buses-2137.html

Original:Scania VCI2 VCI3 SDP3 2.32 Win7/8/10 download: 100% tested

Free Download Professional EGR Remover 02.2016 version

Professional EGR Remover 02.2016 version FULL download free & installation | | Car Diagnostic Tool

NEW! Professional DPF+EGR REMOVER 3.0 Lambda Hotstart Flap,O2, DTC 2 SOFTWARE FULL is newly released on www.chinacardiags.com and sales for only $79.

OK on:

FGTECH Galletto, KESS V2, KTAG Master, MPPS, CMD works (Confirmed)

Support professional DPF-EGR programs (Confirmed)

Support Bosch, Siemens, Dense, Visteon, Delphi, Marelli, Transtron ECU ! (Confirmed)

OK on WIN XP , WIN7 , WIN8.1, WIN10 (32 + 64 bit) (Confirmed)

Multilanguage available: English, German, French, Spanish, Italian, Turkish, Slovak - Czech, Romanian, Portuguese, Polish, Dutch (Confirmed)

Following parts include: 1, Professional DPF+EGR REMOVER 3.0 Lambda Hotstart Flap,O2, DTC 2 SOFTWARE FULL free download link, 2. installation guide 3. full details.

1. Professional DPF \ FAP - FLAP Remover02.2016 version FULLfree download:

https://mega.nz/#F!zV1USZZL!X2mHnpX3Xc09sqYXlOAVgw

Original:Free Download Professional EGR Remover 02.2016 version

2018 KEYDIY KD-X2 Review: First, Best, Cheapest 48 Cloning Tool

Post vehicles and chips used for cloning with a KD-X2 KEYDIY remote maker remote makers.

Big thanks to all user feedback

Look here: KEYDIY KD-X2 Reviews: Success & Failure

VW polo 48: successful

VW Passat B6 2010: successful to clone 48. Online on 48 transponder:

2013 Chevy Captive (CN3 chip): successful

Fiat Panda 2001 id33 of T5 and NB multifunctional: successful

Passat B7 2013: successful

Passat B6 2010: successful

2011 Chevy Captiva (CN3 chip): successful

Ford Focus 2003 (CN5): successful

2003 Honda Accord (T5 chip): successful

Suzuki swift 2007 Cn3: successful

Citroen C3 2014 cn3: successful

Citroen c5 2007 (nb multifunctional): successful

Yamaha motorbike cn5: successful

Toyota aygo ID70 on LKR02 /cn2: successful

Ford Focus 2003 cloning CN5: successful (CN5 for 4D.)

Suzuki swift 2007 Cn3: successful

Yamaha motorbike cn 5: successful

Citroen C3 2014 cn3: successful

Europe Citroen C1: successful

Peugeot 107: successful

Toyota aygo ID70 on LKR02 /cn2: successful

wv polo key 48 transponder: successful in the 48 original trasnpondar cloning online

vw polo white meter: successful

Passat B7 2013: successful to clone 48 transponder

Cloned a Polo 2009 and a Daf LF truck id48 on a normal blank id48 transponder: successful

Passat B6 2010 and Passat B7 2013: successfully add regular 48

Fiat 48 transponder cloning: successful. Already used CN6 with CN900 mini with firmware update.

Vw transporter T5 2013: successful, calculate id48 and copy well

Citroen c5 done perfectly 2007 (nb multifunctional): successful

transponder cloning then re synced remote

to resync remote, you can not program only remote but when the chip is generated it can work but still will fail from time to time download "wikirke" on your phone

Vw Polo 2007 successfully on CN 6: successful

Interesting note: At the stage when need to verify original key, kdx device turned off and kd soft asked to check equipment etc. But when turned on kd again everything finished fine.

Passat B7 2013clone 48 transponder: successful

possible to clone on regular 48 transponder

They are wizzards with special powers

Online cloning with 150 free coins earned after generating B or NB remotes. On regular 48 transponder.

Cloning in kdx2: I had no problem sniffing data

X2 turns off to save battery. Calculations are done on a server and sent back to X2 once completed.

Kdx2 copy 4C to YS01 chip (old cn900 that can use as 4C/4D): successful

1999 Ford F-150: failed!

Summary:

SoKD-X2 Keydiy Key Clonning Toolis the first clonemachine who can clone on regular id48...

The best and cheapest 48 cloning tool!!!

This from https://www.chinacardiags.com/ : 2018 KEYDIY KD-X2 Review: First, Best, Cheapest 48 Cloning Tool

SBB Pro2/SBB key programmer v48.88 car list

SBB Pro2 key programmer v48.88 car list: SBB PRO2 Key Programmer Updated to V48.88 Version.Supports new cars to 2017.12. like Acura 2017,Chevrolet 2017,Buick 2017, Cadillac,GMC 2017,Ford 2017,Dodge 2017,Toyota 2017... SBB V33.01 works to 2011.12, SBB key programmer V46.02 works to 2015.12. ACURA CL&TL 99-03. INTEGRA 00-01. MDX 01-06. MDX 07-09. NSX 97-05. RDX 07-16. RL 96-04. RSX 02-06. TL 04-06. TL 07-08. TL 09-17. TSX 04-06. TSX 07-08. TSX 09-17. ALFA ROMEO GT CAN 03-16. 147 CAN 00-17. 156 98-01. 156 01-03. 156 03-05. 156SPORT WAGO 00-01. 156SPORT WAGO 01-07. 166 98-04. 166 04-08. AUDI ALLROAD 00-04. A2 00-04. A3 96-97. A3 97-04. A4 95-96. A4 96-97. A4 97-04. A6 95-96. A6 96-97. A6 97-04. A8 95-96. A8 97-04. CABRIO 95-96. CABRIO 96-97. CABRIO 97-04. Coupe 95-96. Coupe 96-97. Coupe 97-04. Coupes2 95-96. Coupes2 96-97. Coupes2 97-04. S3 01-04. S4 00-05. S6 95-96. S6 96-97. S6 97-04. S8 97-04. TT 98-04. 80 96-. AUDI USA A4 02-05. A6 01-05. A8 01-02. S4 02-05. S6 01-05. TT COUPE 01-06. BUICK BASIC LESABRE 00-05. PARK AVE. 97-04. RENDEZVOUS 02-04. BUICK[CAN] ALLURE 05-09. ENCLAVE 07-17. GM TYPE7-CAN 10-17. LACROSSE 05-09. LUCERNE 06-17. TERRAZA 05-07. CADILLAC BASIC CATERA 97-00. CATERA 01-02. CTS 03-07. DEVILLE-STS 00-05. SEVILLE 97-03. CADILLAC[CAN] CTS 08-17. DTS 06-17. ESCALADE 07-16. SRX 04-06. SRX 07-16. CHEVROLET S.AMERICA AGILE[CAN] 09-17. ASTRA 01-17. BLAZER 06-08. BLAZER 08-17. CAPTIVA[CAN] 08-17. CELTA 00-16. CORSA 95-98. CORSA 98-99. CORSA 00-17. CORSA HATCH 00-. MERIVA 02-.17 MONTANA 03-17. OMEGA 95-98. PRISMA 06-17 S-10 06-08. S-10 08-. VECTRA 05-. VECTRA 09-. ZAFIRA 99-00. ZAFIRA 01-05. CHEVROLETUS BASIC venture 99-04. CHEVROLET US CAN AVALANCHE 07-16. COBALT 05-10. EQUINOX 07-09. EXPRESS 08-17. HHR 06-13. IMPALA 06-13. MALIBU 04-17. M.TE CARLO 06-08. SILVERADO 07-17 SUBURBAN 07-17. TAHOE 07-16. TRAVERSE 09-17 UPLANDER 05-08. CHEVROLET-DAEWOO ESPERO 95-97. EVANDA 03-17. KALOS 02-06. LACETTI 04-09. LANOS 97-02. LANOS 02-04. LEGANZA 97-00. LEGANZA 00-02. LEGANZA 02-17. LEGANZA[USA] 01-17. MATIZ 98-00. MATIZ 01-05. MATIZ 06-17. NEXIA 95-97. NUBIRA 97-00. NUBIRA 00-02. NUBIRA 03-06. TACUMA 00-02. TACUMA 02-08. CHRYSLER ASPEN[CAN 07-09. CIRRUS 99-00. CIRRUS SONV. 01-02. CIRRUS SEDAN 01-02. CONCORDE 98-04. LHS 99-04. NEON 00-05. NEW YORKER 99-04. PACIFICA 04-08. PT CRUISER 01-05. PT CRUISER LE 01-05. PT CRUISER[CAN 06-17. SEBRING C. 01-06. SEBRING C[CAN] 07-17. SEBRING 2 DR. 01-05. SEBRING 2 DR. 99-06. SEBRING[CAN] 07-11. SEBRIGN[CCD] 98-02. STRATUS 2 DR. 01-05. STRATUS 4 DR. 99-06. STRATUS[CCD] 98-01. wown&co[byp 08-17 TOWN&COUNTRY 01-03. TOWN&COUNTRY 04-07. TOWN&COUN[CAN] 08-09. TOWN&COUN[CAN] 10-17. VISION 98-02. VOYAGER 00-03. VOYAGER 04-06. VOYAGER[CCD] 98-01. 200[CAN] 11-17 300 99-04. 300CAN 05-06. 300CAN 06-08. 300CAN 08-09. 300CAN 09-11. 300[KGO] 12-17. CITROEN BERLINGO 01-02. BERLINGO SB 98-01. BERLINGO SV 98-01. C2 03-05. C2[CAN] 06-17. C3 02-05. C3[CAN] 06-17. C4 06-17 C5 01-05. C5[CAN] 06-08. C6[CAN] 06-17. C8 02-05. C8[CAN] 05-17. EVASION[SB] 98-02. EVASION[SC] 98-02. JUMPY[SC] 99-02. JUMPY[SV] 99-02. SAXO 98-00. SAXO 00-03. XANTIA 98-99. XANTIA SB 99-01. XANTIA SC 99-01. XSARAPICASSO 00-06. XSARA SB 98-01. XSARA SB 01-06. XSARA SC 98-01. XSARA SC 01-06. DODGE AVENGER CAN 08-17. CALIBER CAN 07-17. CARAVAN 01-03. CARAVAN 04-07. CARAVAN BYP 08-17. CARAVAN CAN 08-09. CARAVAN CAN 10-17. CHALLENGE CAN 08-17. CHALLENGE KGO 12-17. CHARGER CAN 05-06. CHARGER CAN 06-08. CHARGER CAN 08-09. CHARGER CAN 09-17. CHARGER KGO 12-. DAKOTA 01-02. DAKOTA 03-04. DAKOTA CAN 05-06. DAKOTA CAN 07-17. DURANGO 01-03. DURANGO 03-04. DURANGO CAN 04-06. DURANGO CAN 07-09. DURANGO CAN 11-. INTREPID 98-04. INTREPID ES 01-02. INTREPID SED. 01-02. JOURNEY BYP 08-17. JOURNEY CAN 08-10. JOURNEY CAN 10-17. JOURNEY KGO 12-17. MAGNUM CAN 05-06. MAGNUM CAN 07-08. MAGNUM CAN 08-09. MAGNUM CAN 09-17. NEON 00-05. NITRO CAN 07-17. RAM 02-05. RAM CAN 06-11. RAM CAN 09-17. STRATUS 2 DR. 01-05. STRATUS 4 DR. 99-06. STRATUS CCD 98-01. EAGLE VISION 98- FIAT DAILY[CAN 00-. DOBLO CAN 00-06. DUCATO 02-05. IDEA CAN 03-08. MULTIPLA 98-03. PALIO CAN 02-. PANDA CAN 02-. PUNTO CAN 99-. SEDICI D 06-. SEDICI G 06-17. SEICENTO 00-10. SIENA CAN 02-07. SITLO CAN 01-07. ULYSSE BSI 02-05. ULYSSE CAN 05-11. 500 CAN 07-. FIAT SIAMERICA DOBLO CAN 00-06. DOBLO CAN 06-. IDEA CAN 03-08. IDEA CAN 09-. MILLE 05-. PALIO CAN 04-08. PALIO CAN 09-. PUNTO CAN 99-07. PUNTO CAN 07-. SIENA ARG 09-17. SIENA BRA 09-17. SIENA CAN 02-07. STILO CAN 02-08. STILO CAN 09-. STRADA CAN 05-. FIAT-PSA PHEDRA BSI 02-05. PHEDRA CAN 05-11. SCUDO SC 96-01. SCUDO SV 96-01. ULYSSE BSI 02-05. ULYSSE CAN 05-17. FORD AUS B-SERIES PCM 01-04. B-SERIES P2 99-01. ESCAPE CAN 05-. ESCAPE PCM 01-04. EXPLORER CAN 04-. EXPLORER PCM 01-03. EXPLORER P2 98-00. EXPL.STRA PCM 02-05. EXPL.STRAC P2 99-01. FOCUS CAN 03-04. FOCUS CAN 05-. FOCUS PCM 00-04. S-TYPE 02-. TAURUS CAN 04-. TAURUS PCM 00-03. TAURUS P1 96-97. TAURUS P2 98-99. TRIBUTE PCM 01-03. 121 96-01. FORD EU COUGAR 97-02. COURIER 97-02. COURIER 2KD 97-99. ESCORT 95-96. ESCORT MK 96-97. ESCORT MKB 96-97. ESCORT MKD 96-97. FIESTA 95-96. FIESTA 00-02. FIESTA MK 96-97. FIESTA MKB 96-97. FIESTA MKD 96-97. FIESTA 2K 97-00. FIESTA 2KD 97-00. FIESTA 3KD 97-00. FOCUS 98-02. galaxy1.9 98-00. galaxy1.9 00-03. galaxy 2.3 2K 98-00. galaxy 2.3 2K 00-02. GALAXY MKB 96-97. GALAXY MKB 96-97. KA 96-02. KA MK 96-97. KA MKB 96-97. MONDEO 95-96. MONDEO 01-02. MONDEO MK 96-97. MONDEO mkb 96-97. MONDEO mkd 96-97. MONDEO 2K 97-00. MONDEO 2KD 97-00. MONDEO 3KD 97-00. PUMA 98-02. SCORPIO 2K 97-00. S-TYPE 00-02. transit 95-96. transit 00-02. transit mk 96-97. transit mkb 96-97. tramsit mkd 96-97. transit 2k 97-99. transit 2kd 97-99. transit 3kd 97-99. FORD SUD AMERICA ECO SPORT CAN 03-07. ESCORT 98-02. EXPLORER USA 04-17. FIESTA MA CAN 05-17. FIESTA CAN 03-17. FOCUS 98-07. FOCUS CAN 08-17. F-100 00-05. KA CAN 08-17. FORD USA FORD USA CONTOUR V PCM 99-00. CONTOUR P1 97-99. CROWN VIC CAN 05-06. CROWN VIC CAN 07-17 CROWN VIC PCM 03-04. CROWN VIC P2 98-02. EDGE CAN 07-09. EDGE CAN 10-10. EDGE CAN 11-17. ESCAPE CAN 05-07. ESCAPE CAN 08-09. ESCAPE CAN 10-17. ESCAPE PCM 01-04. E-SERIES CAN 08-09. E-SERIES CAN 10-17. excursion P2 00-05. EXPEDITIO CAN 05-06. EXPEDITIO CAN 07-08. EXPEDITIO CAN 09-17. EXPEDITIO HEC 99-02. EXPEDITIO PCM 03-04. EXPEDITIO P1 97-98. EXPLOREER CAN 04-05. EXPLOREER CAN 06-09. EXPLOREER CAN 10-10. EXPLOREER CAN 11-. EXPLOREER PCM 01-03. EXPLOREER P2 98-00. EXPL.STRA CAN 07-09. EXPL.STRA CAN 10-17. EXPL.STRA PCM 02-06. EXPL.STRA P2 99-01. FIESTA CAN 11-. FIESTA CAN 12-17. FIESTA prx 11-. five hund can 05-07. flex can 09-. flex can 10-. FLEX CAN 11-17. focus can 05-07. focus can 06-07. FOCUS CAN 08-10. focus can 11-. FOCUS CAN 12-17. FOCUS PCM 00-04. FREESTAR CAN 06-17. FREESTAR PCM 04-05. FREESTYLE CAN 05-07. FUSION CAN 06-09. FUSION CAN 10-17. F-150 CAN 04-08. F-150 CAN 09-10. F-150 CAN 11-17. F-150 HEC 99-04. F-150 P2 98-00. F-250 SD CAN 08-09. F-250 SD CAN 10-10. F-250 SD CAN 11-17 F-250 CAN 04-08. F-250 CAN 09-10. F-250 CAN 11-. F-250 HEC 99-04. F-250 P2 98-00. F-350 SD CAN 08-09. F-350 SD CAN 10-10. F-350 SD CAN 11-17. F-350 HEC 99-03. F-350 P2 99-03. GT-2 05-06. MUSTANG CAN 05-09. MUSTANG CAN 07-10. MUSTANG CAN 10-17. MUSTANG CAN 11-17. MUSTANG HEC 99-04. MUSTANG P1 97-98. MUSTANG P2 98-99. RANGER V6 BRAZ 00-00. RANGER V6 PCM 01-04. RANGER V6 PCM 06-06. RANGER V6 P2 99-00. RANGER XLT P2 99-00 RANGER CAN 07-10. TAURUS X CAN 08-08. TAURUS X CAN 09-09. TAURUS CAN 04-07. TAURUS CAN 08-08. TAURUS CAN 09-09. TAURUS CAN 10-. TAURUS PCM 00-03. TAURUS PRX 10-. TAUTUS P1 96-97. TAUTUS P2 98-99. T-BIRD ICM 02-05. T-BIRD ICM 02-05. WINDSTAR CAN 07-. WINDSTAR ICM 99-00. WINDSTAR PCM 01-06. WINDSTAR P2 99-00. GMC ACADIA 07-12. SAVANA 08-11. SIERRA 07-13. YUKON 07-09. HOLDEN ASTRA 95-98. ASTRA 98-01. ASTRA 01-04. ASTRA CAN 04-. BARINA 95-98. BARINA 98-99. BARINA 00-04. BARINA 04-06. COMBO 98-01. FRONTERA 96-99. FRONTERA 99-. VECTRA 95-98. VECTRA 98-04. VECTRA CAN 04-. ZAFIRA CAN 04-. HONDA ACCORD 99-03. ACCORD ULEV 99-03. ACCORD 1 03-06. ACCORD 2 03-06. CIVIC 02-05. CR-V 02-06. HR-V 02-05. JAZZ 01-07. STREAM 01-03. HONDA USA ACCORD 98-02. ACCORD 03-08. ACCORD 09-17. ACCORD CROSST 10-17. ACCORD ULEV 98-02. CIVIC 01-02. CIVIC 03-05. CIVIC 06-13. CIVIC HYBRID 03-05. CR-V 02-05. CR-V 07-13. CR-Z 11-17. ELEMENT 03-05. ELEMENT 06-07. ELEMENT 07-17. FIT 07-08. FIT 10-17 INSIGHT 00-06. INSIGHT 10-17. ODYSSEY 98-02. ODYSSEY 03-04. ODYSSEY 05-06. ODYSSEY 07-10. ODYSSEY 11-17. PILOT 03-05. PILOT 06-08. PILOT 09-17. PRELUDE 97-02. RIDGELINE 05-08. RIDGELINE 09-11. S2000 00-02. S2000 03-05. S2000 06-09. HUMMER CAN H2 08-09. H2 SUT 08-09. HYUNDAI ACCENT 96-99. ACCENT 99-06. ACCENT CAN 06-11. ATOS 97-00. ATOS PRIME 99-01. ATOS PRI TYP2 02-08. COUPE 96-01. COUPE 01-07. ELANTRA CAN 07-17. ELANTRA D CAN 07-17 ELANTRA USA 96-00. ELANTRA USA 00-06. EXCEL 96-99. EXCEL 99-. CALLOPER 99-03. GETZ 02-09. GETZ TYP2 02-09. GRAND. CAN 06-. GRAND.D CAN 06-. H-1 99-06. H-1.D CAN 06-17. LANTRA 96-00. MATRIX 02-10. SANTAFE 00-02. SANTAFE 02-06. SANTAFE CAN 06-17. SANTAMO 00-03. SCOUPE 96-. SONATA 96-98. SONATA 98-04. SONATA D CAN 05-17. SONICA 96-99. SONICA 99-04. STAREX 98-06. TERRACAN 01-07. TRAJET 00-06. TUCSON D 05-17. V.CRUZ CAN 07-17. V.CRUZ D CAN 07-17. HYUNDAI USB ACCENT 06-11. AZERA 05-06. AZERA CAN 07-10. GENESIS 09-10. TIBURON 06-07. INFINITI EX35 PRX 08-11. FX35 IK 03-11. FX35 NT5 03-09. FX45 IK 03-09. FX45 NT5 03-09. FX50 IK 09-11. G20 00-02. G35 03-07. G35 IK 05-08. G35 PRX 07-08. G37 PRX 09-13. I30 99-00. I30 01-04. I35 01-04. M35 03-06. M45 03-06. QX4 99-00. QX4 01-03. QX56 04-07. QX56 IK 08-12. Q45 97-00. Q45 01-06. JAGUAR S-TYPE 00-02 JEEP CHEROKEE 98-04. CHEROKEE CCD 98-04. CJ5 CJ7 98-05. COMMANDER CAN 06-07. COMMANDER CAN 08-09. COMMANDER CAN 09-10. COMPAS CAN 07-17. G.CHEROK BYP 08-. G.CHEROKEE 98-04. G.CHEROKE CAN 05-06. G.CHEROKE CAN 07-08. G.CHEROKE CAN 08-10. G.CHEROKE CAN 11-. LIBERTY 02-04. LIBERTY 05-07. LIBERTY CAN 08-17. PATRIOT CAN 07-17. WRANGL.R CAN 07-17. WRANGL.U CAN 07-17. WRANGLER 98-06. WRANGLER CCD 98-00. KIA CARENS 01-06. CARENS 01-06. CARENS CAN 06-07. CARENS CAN 07-17. CARNIVAL 02-05. CARNIVAL CAN 06-17. CARNIVAL RYP2 02-05. CEE'D CAN 07-17. CERATO 04-06. CERATO D CAN 07-17. CERATO CAN 07-17 CLARUS 98-01. JOICE 00-03. MAGENTIS 01-06. MAGENTIS CAN 06-17. MORNING D CAN 06-17. OPTIMA CAN 06-17. PICANTO 04-08. PICANTO D CAN 06-08. PICANTO TYP2 04-08. PICANTO CAN 08-11. PRIDE 99-01. RIO 01-06. RIO CAN 06-. SEDONA 02-05. SEDONA D CAN 06-17. SEPHIA 02-04. SHUMA 98-01. SORENTO 02-05. SORENTO CAN 06-07. SORENTO CAN 07-17. SOUL CAN 09-17. SPORTAGE 98-99. SPORTAGE 99-01. SPORTAGE 01-03. SPORTAGE CAN 06-. KIA USA AMANTI 04-07. AMANTI CAN 07-09. BORREGO CAN 09-11. FORTE CDN 08-11. OPIRUS 04-07. LANCIA LYBRA 99-06. PHEDRA BSI 02-05. PHEDRA CAN 05-17. THESIS CAN 02-09. YPSILON CAN 03-06. LEXUS ES300 02-03. ES330 04-06. GS300 02-05. GS430 01-05. GX470 03-07. IS300 01-05. LS430 01-04. LS430 04-06. LX470 01-02. LX470 03-06. RX330 04-06. RX350 07-09. RX400H 05-09. SC430 02-10. LINCOLN AVIATOR PCM 03-07. BLACKWOOD HEC 02-03. CONTINENTAL 02-03. CONTINENT HEC 98-02. CONTINENT ICM 98-02. CONTINENT P2 98-02. LS ICM 00-06. LS PCM 03-06. MARK LT CAN 05-08. MARK LT CAN 08-09. MKS PRX 09-17. MKT PRX 10-17. MKX CAN 07-17. MKX CAN 11-17. MKZ CAN 07-09. MKZ CAN 10-17. NAVIGATOR CAN 05-06. NAVIGATOR CAN 07-08. NAVIGATOR CAN 09-17. NAVIGATOR HEC 99-02. NAVIGATOR PCM 02-04. NAVIGATOR P1 97-98. NAVIGATOR P2 99-99. TOWN CAR CAN 05-10. TOWN CAR CAN 07-. TOWN CAR HEC 98-02. TOWN CAR PCM 03-04. ZEPHYR CAN 07-17. MAZDA B-SERIES CAN 07-17. B-SERIES PCM 01-06. B-SERIES P2 99-00. CX-7 CAN 07-17. CX-7 PRX 10-11. CX-7 TYP1 07-08. CX-7 TYP2 07-08. CX-9 CAN 07-16. CX-9 PRX 09-11. CX-9 TYP1 07-08. CX-9 TYP2 07-08. MAZDA 2 CAN 11-. MAZDA 3 CAN 10-17. MAZDA 3 PRX 10-11. MAZDA 3 TYP1 04-09. MAZDA 3 TYP2 04-09. MAZDA 5 CAN 08-17. MAZDA 5 TYP1 06-07. MAZDA 5 TYP2 06-07. MAZDA 6 CAN 08-11. MAZDA 6 PRX 09-11. MAZDA 6 TYP1 03-07. MAZDA 6 TYP2 03-07. MX-5 CAN 06-11. MX-5 RPX 09-13. RX-8 CAN 09-10. RX-8 PRX 09-11. RX-8 TYP1 04-08. RX-8 TYP2 04-08. TRIBUTE CAN 05-07. TRIBUTE CAN 08-08. TRIBUTE CAN 09-09. TRIBUTE CAN 10-11. TRIBUTE pcm 01-04. 121 97-01. MERCURY COUGAR PCM 99-02. COUGAR P2 98-99. GR.MARQUI CAN 05-10. GR.MARQUI PCM 03-04. GR.MARQUI P2 98-02. MARAUDER PCM 03-05. MARAUDER CAN 05-07. MARAUDER CAN 08-08. MARAUDER CAN 09-09. MARAUDER CAN 10-. MILAN CAN 06-09. MILAN CAN 10-17. MONTEGO CAN 05-06. MONTEGO CAN 07-17. MONTEREY CAN 06-07. MONTEREY PCM 04-05. M.TAINEER CAN 04-05. M.TAINEER CAN 06-09. M.TAINEER CAN 10-17. M.TAINEER PCM 01-04. M.TAINEER P2 98-01. MYSTIQUE P1 97-98. MYSTIQUE P2 98-99. SABLE CAN 04-07. SABLE CAN 08-17. SABLE PCM 00-03. SABLE P1 96-97. SABLE P2 98-99. MITSUBISHI CARISMA 96-00. CARISMA 00-04. COLT 96-00. ECLIPSE 96-00. ECLIPSE 00-02. ECLIPSE 02-03. GALANT PIN1 96-00. GALANT PIN1 00-02. GALANT PIN1 02-05. GALANT PIN2 96-00. GALANT PIN2 00-02. GALANT PIN2 02-05. LANCER 96-03. LANCER 03-06. LANCER SW 96-03. L200 99-02. L200 02-06. MONTERO 96-00. MONTERO 01-06. MONTERO 02-05. MONTERO 02-03. MONTERO IO 00-06. MONTERO SPORT 99-02. MONTERO SPORT 01-04. NATIVA 01-02. PAJERO 96-00. PAJERO 00-02. PAJERO 02-03. PAJERO 02-05. PAJERO IO 99-04. PAJERO PININ 99-04. PAJERO PININ 99-04. PAJERO SPORT 99-02. PAJERO SPORT 02-03. SHOGUN 96-00. SHOGUN 00-02. SHOGUN 02-03. SHOGUN 02-05. SHOGUN PININ 99-04. SHOGUN SPORT 99-02. SHOGUN SPORT 02-03. SPACE GEAR 96-. SPACE RUNNER 98-99. SPACE RUNNER 99-02. SPACE STAR 99-. SPACE STAR 99-. SPACE WAGON 98-99. SPACE WAGON 99-03. 3000GT 96-01. mitsubishi australia challenger 99-02. challenger 02-03. EXPRESS 96-. LANCER 96-03. LANCER 03-06. LANCER SW 96-03. MAGNA 96-99. MAGNA 99-05. MIRAGE 96-02. NIMBUS 98-99. NIMBUS 99-02. PAJERO 96-00. PAJERO 00-02. PAJERO 02-03. PAJERO IO 99-04. TRITON PIN1 99-. TRITON PIN2 99-. verada 96-00. verada 96-02. MITSUBISHI GREEK CARISMA 96-00. CARISMA 00-04. COLT 96-00. COLT NEW 02-. GALANT 96-00. GALANT 00-02. GALANT 02-05. LANCER 96-03. LANCER SW 96-03. L200 99-02. L200 02-06. PAJERO 96-00. PAJERO NEW 00-02. PAJERO NEW 02-03. PAJERO PININ 99-04. PAJERO SPORT 99-02. PAJERO SPORT 02-03. SPACE GEAR 96-. SPACE RUNNER 98-99. SPACE RUNNER 99-02. SPACE STAR 99-. 3000 GT 96-. MITSUBISHI USA DIAMANTE 00-02. DIAMANTE 02-06. ECLIPSE 96-00. ECLIPSE 00-02. ECLIPSE 01-05. ECLIPSE CAN 06-07. ECLIPSE CAN 07-17. endeavor 03-05. endeavor CAN 06-07. endeavor CAN 07-17. GALANT 04-05. GALANT CAN 06-07. GALANT CAN 08-13. GALANT PIN1 96-00. GALANT PIN1 00-02. GALANT PIN1 02-03. GALANT PIN2 96-00. GALANT PIN2 00-02. GALANT PIN2 02-03. LANCER 96-03. LANCER evo 03-06. LANCER SW 96-03. LANCER CAN 08-09. MONTERO 96-00. MONTERO 01-06. MONTERO 02-03. MONTERO SPORT 99-02. MONTERO SPORT 01-04. OUTLANDER 00-03. OUTLANDER 04-06. OUTLANDER CAN 07-09. NISSAN ALMERA 99-00. ALMERA 00-03. ALMERA TINO 00-03. ALTIMA 00-04. INFINITI 05-. INTERSTAR 02-07. MAXIMA 95-99. MAXIMA 00-03. MICRA 96-98. MICRA 98-00. MICRA 00-04. MICRA 03-. MICRA 03-. MICRA VAN 00-00. MICRA VAN 00-03. NAVARA 00-03. NAVARA 03-05. NOTE 06-. NOTE 06-. NX ALMERA 95-98. NX ALMERA 98-00. PATHFINDER 99-. PATROL 98-03. PRIMERA 95-96. PRIMERA 97-98. PRIMERA 98-00. PRIMERA 00-02. PRIMERA 02-08. PULSAR 95-96. PULSAR 97-98. PULSAR 98-00. PULSAR 00-04. SENTRA 00-06. SERENA 96-99. TERRANO II 95-98. TERRANO II 98-01. TERRANO 3000D 98-01. VANETTE 96-99. VANETTE 99-00. VANETTE 00-. XTERRA 00-04. X-TRAIL 98-05. 350Z 03-. NISSAN JAPAN CEFRIO 00-03. INF INITI 97-99. LAUREL 99-00. LAUREL 00-02. MICRA MARCH 96-98. MICRA MARCH 98-00. MICRA MARCH 00-03. SUNNY 96-98. X-TRAIL 98-00. X-TRAIL 01-05. NISSAN TRUCKS ATLEON 02- CAB STAR 00- NISSAN USA ALTIMA 00-. ALTIMA 01-04. ALTIMA 05-06. ALTIMA CPPRX 07-12. ALTIMA SEPRX 07-12. ARMADA 04-07. ARMADA IK 08-11. ARMADA NT5 08-12. CUBE NT5 09-11. CUBE PRX 09-11. FRONTIER 05-17. JUKE NT5 11-17. JUKE PRX 11-17. LIVINA NT5 07-08. LIVINA PRX 07-08. MAXIMA 99-00. MAXIMA 00-03. MAXIMA 04-07. MAXIMA IK 08-17. MAXIMA PRX 09-11. MURANO 03-08. MURANO IK 05-08. MURANO NT5 03-08. MURANO PRX 09-10. NV SERIER NT5 12-. PATHFINDER 99-00. PATHFINDER 01-04. PATHFINDER 05-07. PATHFINDER IK 08-11. PATHFINDER NT5 08-17. QUEST 04-07. QUEST NT5 08-10. QUEST PRX 11-17. ROGUE IK 07-15. ROGUE NT5 07-15. SENTRA 00-06. SENTRA IK 07-12. SENTRA NT5 07-17. TIIDA NT5 07-08. TITAN 04-07. TITAN 07-08. TITAN NT5 08-13. VERSA IK 07-12. VERSA NT5 07-13. XTERRA 03-04. XTERRA 05-07. XTERRA NT5 08-12. 350Z 03-07. 350Z ROADSTER 04-07. 350Z IGN 08-08. 370Z PRX 09-10. OLDSMOBILE BASIC AUTOTA 01-03. SILHOUETTE 99-04. OPEL-VAUXHALL AGILA 00-04. AGILA 04-08. ASTRA 95-98. ASTRA 98-01. ASTRA 01-04. ASTRA CAN 04-17. CALIBRA 95-98. COMBO 98-01. COMBO 01-16. CORSA 95-98. CORSA 98-99. CORSA 00-04. CORSA 04-06. CORSA CAN 06-17. FRONTERA 96-99. FRONTERA 99-03. MERIVA 02-04. MERIVA 04-17. MOVANO 98-01. MOVANO 02-07. OMEGA 95-98. OMEGA 98-01. signum can 03-08. SINTRA 97-99. TIGRA 95-98 TIGRA 98-01. TIGRA 01-02. VECTRA 95-98. VECTRA 98-02. VECTRA CAN 03-08. ZAFIRA 99-01. ZAFIRA 01-05. ZAFIRA CAN 06-. PEUGEOT PARTNER 01-03. PARTNER SB 98-01. PARTNER SV 98-01. RANCH 01-03. RANCH SB 98-01. RANCH SV 98-01. 1007 04-12. 106 9-01. 106 01-02. 107 05-. 206 98-01. 206 01-02. 206 02-03. 207 CAN 06-. 306 SB 97-02. 306 SC 97-02. 307 01-03. 307 CAN 04-09. 406 99-02. 406 02-04. 406 SB 97-99. 406 SC 97-99. 406 SV 97-99. 407 CAN 04-13. 607 01-03. 806 SB 98-02. 806 SC 98-02. 807 01-05. 807 CAN 05-. PONTIAC BASIC AZTEK 01-05. BONNEVILLE 00-05. GRAND PRIX 00-03. GRAND PRIX 04-08. MONTANA 99-04. PONTIAC CAN G5 07-17. G6 05-10. G8 08-09. MONTANA 05-08. PURSUIT 06-10. SOLSTICE 06-09. TORRENT 07-09. RENAULT AVANTIME 01-03. CLIO 01-05. KANGOO 01-07. LAGUNA 01-07. MASTER 02-07. MEGANE 98-00. MEGANE 01-03. MEGANE CAN 03-08. MODUS 04-07. TWINGO 02-07. RENAULT-DACIA LOGAN 06-. SANDERO 08-. SYMBOL 10-16. SAAB USB CAN 9-7 USA 06-08. SATURN CAN AURA 07-09. OUTLOOK 07-10. RELAY 05-07. SKY 07-17. VUE 07-09. SCION TC 05-07. TC CAN 08-17. TC CAN 11-. SEAT ALHAMBRA 96-98. ALHAMBRA 98-00. ALHAMBRA 00-. ALTEA ZL CAN 06-06. ALTEA CAN 04-06. AROSA 97-99. AROSA 99-01. AROSA 01-05. CORDOBA 95-98. CORDOBA 99-02. CORDOBA 02-09. IBIZA 95-98. IBIZA 98-02. IBIZA 02-09. INCA 96-98. INCA 98-00. INCA 00-03. LEON 00-05. LEON CAN 05-06. MARBELLA 97-98. TOLEDO 95-99. TOLEDO 97-99. TOLEDO 00-04. TOLEDO CAN 05-06. SKODA FABIA 00-06. FELICIA 96-98. FELICIA 98-01. OCTAVIA 97-00. OCTAVIA 01-04. OCTAVIA CAN 04-06. PICK-UP 96-98. PICK-UP 98-00. ROOMSTER CAN 06-06. ROOMST.SC CAN 07-07. SUPERB 02-06. SUBARU BAJA 05-07. B9 TRIBECA 06-10. FORESTER 98-03. FORESTER 04-08. FORESTER 09-10. IMPREZA 04-07. IMPREZA 07-17. LEGACY 05-. OUTBACK 05-. SUZUKI ALTO 96-02. BALENO 96-01. GRAND VITARA 96-02. GRAND VITARA 02-. IGNIS 00-. IGNIS 00-. IGNIS D 00-. IGNIS D 00-. JIMNY 99-02. JIMNY 02-. LIANA 01-03. SWIFT 96-04. SWIFT 05-. SWIFT D 05-. SX4 D 06-. SX4 G 06-12. VITARA 96-02. VITARA 02-08. WAGON R 98-00. WAGON R 00-08. WAGON R D 98-00. WAGON R D 00-08. SUZUKI USA CAN XL-7 07-09. TOYOTA USA AVALON CAN 07-08. AVALON PRX 05-09. CAMRY CAN 07-10. CAMRY CAN 11-17. CAMRY PRX 11-17. CAMRY TYPE 1 02-04. CAMRY TYPE 2 03-06. COROLLA 05-08. COROLLA CAN 09-10. COROLLA CAN 10-17. FJCRUISER 07-08. FJCRUISER CAN 08-10. FJCRUISER CAN 11-17. HIGHLANDER 01-03. HIGHLANDER 04-07. HIGHLANDER CAN 08-10. HIGHLANDER PRX 08-09. HILUX CAN 04-09. LAND CRUISER 01-02. LAND CRUISER 03-06. MATRIX 05-07. MATRIX CAN 08-17. PRADO 06-17. PRIUS 04-08. PRIUS PRX 09-17. RAV 4 06-10. RAV 4 CAN 06-10. PAV 4 CAN 11-17. SEQUOIA 01-02. SEQUOIA CAN 08-10. SEQUOIA CAN 11-17. SIENNA 04-08. SIENNA CAN 08-10. SIENNA CAN 11-17. SIENNA PRX 11-17. SOLARA 02-03. SOLARA 04-06. TACOMA 05-08. TACOMA CAN 09-17. TACOMA CAN 11-17. TUNDRA CAN 07-17. TUNDRA CAN 11-17. VENZA CAN 09-16. VENZA CAN 11-17. VENZA PRX 09-11. YARIS 07-16. YARIS CAN 08-17. 4RUNNER 01-02. 4RUNNER 03-08. 4RUNNER CAN 09-10. 4RUNNER CAN 11-17. 4RUNNER PRX 10-16. TOYOTA-PSA AYGO 05-16. C1 05-14. YARIS 05-15. 107 05-17. VOLKSWAGEN BEETLE 98-04. BORA 98-04. CADDY 95-99. CADDY 98-04. CADDY CAN 05-06. CROSS GOL CAN 06-06. EOS CAN 06-06. EUTO VAN 00-04. FOX 05-08. GOLF 95-98. GOLF 98-04. GOLF CABRIO 95-98. GOLF CABRIO 98-00. GOLF CABRIO 00-04. GOLF CABR CAN 04-06. GOLF CAN 04-06. INDIVIDUA CAN 04-06. JEETA 00-04. JEETA CAN 06-16. LF28 00-04. LUPO 98-00. LUPO 00-05. PASSAT 95-97. PASSAT 97-98. PASSAT 98-04. POLO 95-98. POLO 98-00. POLO 00-01. POLO 01-04. SAVEIRO 99-04. SHARAN 95-98. SHARAN 98-00. SHARAN 00-04. TOURAN CAN 03-06. TRANSPORTER 95-98. TRANSPORTER 98-04. VENTO 95-04. W8 02-04. VOLKSWAGEN S.AMERICA FOX 09-17. GOL 99-04. GOL 05-08. GOL 09-17. GOL TREND 98-04. GOLF 99-04. KOMBI 99-04. PARATI 99-04. SANTANA 2000 98-04. SAVEIRO 99-04. SPACEFOX 05-08. VOYAGE 09-16. VOLKSWAGEN USA BEETLE 00-05. CABRIO 00-05. CABRIOLET 00-05. EURO VAN 00-04. GTI 00-05. JETTA 00-06. PASSAT SEDAN 00-05.

Free Download CGDI Prog BMW F series programming database

Chinacardiags.com share a piece of free CGDI Prog BMW F series programming database.

1.CGDI BMW: BMW F series programming database download:

https://pan.baidu.com/s/1sm1wIAx

After you complete download, the file is like this:

1. Unzip it.

This folder contains these files shown as below.

1. Right click the CGDI icon on the desktop, choose the option "Open the location of the folder".

1. Copy or cut the folder " psdzdata" and paste it into the category. Now you are ready to use F series programming functions.

Please enjoy!

CGDI BMW F series programming feedback:

1. Program F30 326 2013 FEM smart key...OK
2. program F31 smart key FEM...OK

More...

1. CGDI PROG bmw f20 2014 mileage reset OK
2. read ISN DME MSD80 OK 5WK93628
3. the CAS Plug from BMW Multi Tool will work with CGDI, because CAS and OBD connector are BMW standard protocol.

original:Free Download CGDI Prog BMW F series programming database

how to use VVDI2 to make key on Golf 5 from 2005?

Procedure on how to use VVDI2 to make key on Golf 5 from 2005 with VVDI2.

Car model and year:

Golf 5 from 2005

Purpose:

I m making key. The old has been changed because km clock does not work. I v got pincode and CS code. I go to key learn. Diag find the car. do learn. Get message adaptation finish but car not start.

Correct procedure:

With vvdi2:

Old cluster:

Read immo data and mileage. Save file.

New cluster.

Read immo data and mileage. Save file.

Open old cluster immo data file. Write it to cluster. Write original mileage to cluster.

Reset cluster, job done and it will work with original keys. If any problems recode keys, but I never needed it.

The way to read immo for golf 5 can immo 4 car with Xhorse VVDI2:

Immo data cloned from old cluster. It's very easy to do... just plug the VVDI2 device to the car and it will read immo directly.

original: how to use VVDI2 to make key on Golf 5 from 2005?

Download Diagbox V8.42 8.38 8.37 8.35 8.17 Update Software

Here you can download Lexia 3 Diagbox 8.XX all latest software! No pass, free to all!

Update Diagbox V8.17 to V8.37

Update Diagbox V8.35 to V8.38

Update Diagbox V8.38 to V8.42

Update Diagbox V8.42 to V8.46

Note: Diagbox 8.XX software shared here is tested by individuals, but no engineers. Hope it helps but install and try at your own risk!

All download link need No pass, if it require a pass, try: Simple

If you need a Lexia3 PP2000 Diagbox software 100% confirmed OK, you can get Diagbox 7.76 software CD only €8!

(HD Video) How to install Diagbox V7.76 for Lexia-3 PP2000 Peugeot Citroen?

https://www.youtube.com/watch?v=wJJdj3Qspkk

It's saying that Diagbox 8.xx work with both original and clone Lexia 3 PP2000 Diagnostic Tool. (Diagbox 7.82 tested OK, newer version is testing)

Download Diagbox 8.17 to Diagbox 8.37 update: 75.2 MB

https://mega.nz/#!Z0EHmRwB!T4QsYzZxrNiatSoRlacjCw7oghPpb0H200MO03BM2jg

Feedbacks:

Peugeot 307 by PP2000, parameter measurement, def reading, telecode on all computers = OK

Citroen C3 by Lexia, measurement parameters, reading def, different telecoding on just a few calculators = OK

Peugeot 308 T9 by Diagbox, read def and parameters all OK

Run Diagbox 8.17 on WIN7 pro 32= OK, but PP2000 not work showing message "PP2000 is now disable this pc".

Download Diagbox 8.35 to Diagbox 8.38 update: 39.4 MB

https://mega.nz/#!V8VS1Yib!p3MCZCzs8j7ruts2gAJtUPsJTflRIlTr8ZiXNKhTj1c

Feedbacks:

Tested update Diagbox 8.35 on Citroen C8 on Windows XP, 7 and 10

C8 CAN ok. Test telecoding on ABS or BSI ok.

Try PP2000 and Lexia after installing APP-835 (No need to connect to a car, try manually a111111111111111 as VIN and 11111 as RPO).

Download Diagbox 8.38 to Diagbox 8.42 update: 5.1 MB

https://mega.nz/#!49F3VAxS!t1w6Hq0fPubKxC-Zm7D8fjaULpUMhudqv-FXqfcE9es

Download Diagbox 8.42 to Diagbox 8.46 update: 2.8 MB

https://mega.nz/#!doFAAaKD!uTQ9QNW4-F6BBXUwom6vfeR6qtc1CTgvb5tHmGWlVK0

Lexia PP2000 Diagbox Using Tips collected:

1. If App-835 folder is used to update DiagBox 7.xx, then updates 2, 3 and 4 can be used.

-- Ensure you have a backup copy of the file:

"C:\AWRoot\bin\fi\APPDIAG.SYS" before you start.

-- Download and execute the appropriate file for your own setup. The process will copy all necessary files to the updt folder, it will then automatically kill all associated processes to enable overwriting without conflicts.

-- Run DiagBox to start the update process and wait until DiagBox is operational. Once successfully operational, close DiagBox and restart your computer to ensure all processes are running

-- Done..! You may run DiagBox as usual.

1. Lexia language is set to English and PP2000 to French, if you wish to change them, edit the DICO.TXT file in the EXE folders of LEXIA or OUTILREP (PP2000) and replace "GB" with "FR" or vise versa.
2. Notice that DiagBox version will NOT be changed by these updates.
3. DiagBox has been running on Firmware 4.3.4 since 7.66/8.02.

If you wish to revert to your original setup:

- Kill all processes again using the wicked batch file

- Rename the C:\APP folder to anything or delete it

- Rename your C:\APP8 back to C:\APP

- Restart the computer and start DiagBox.

1. Make sure you are running DiagBox as Administrator and the network is disconnected.
2. Before you start DiagBox, navigate to "C:\AWRoot\dtwr\updt\" and delete all contents of the updt folder. Otherwise, it will attempt to update the failed updates that you tried earlier. Do not make changes in "AWRoot".

MultiDiag Access J2534 Pass-Thru AC911777/AC911779 cable

Veuillez connecter un des cables suivants (ou ensembles de cables):

When connect vehicle with Multi-diag access Multidiag actia j2534, the computer prompts to plug the AC911777/AC911779 cables? Which cables in the package should you plug in?

AC911777//AC911779

Please connect the following cables (or cable assemblies):

AC911777//AC911779

Actia Multi-diag j2534Package list:

Multi-Diag Access VCI (Vehicle Communication Interface)

DB25 to OBD-2 Male

Man OBD2 test cable

DIN6 to USB

DIN6 to DB9F cable

AC911777/AC911779 cable in the package:

Multi-Di@g J2534 I.2016 ,I-2014, I-2013 (V2013.01), II-2013 (V2013.02), V2011:

https://www.obd2diy.fr/search/?q=multidiag&DirID=

(Solved) Renault CAN CLIP "Problem in multiplex network"

This is how to solve an issue of your Renault CAN CLIP interface with an error message "Problem in multiplex network"

Almost ALL pcb Renault Can Clip has the bug as a wrong resistors (2 pc) in Low CAN.(Message - "Problem in multiplex network" will be shown)

It's a fairly common problem. The reason to the ugliness is banal - sealed resistors of smaller denomination. Instead of 26.1 kilohms (marking 2612), sealed with 2.61 kOhm (marking 2611).

There is a file that point you what resistors must be replaced. Notice it when chose your Clip. It's in Russian, but a picture explains all.

The solution, I think, does not need to be explained.

This is the best Renault CAN CLIP pcb with AN2135SC

Source: https://www.obd2diy.fr/wholesale/can-clip-for-renault-avec-puce-complete-multi-languages-auto-diagnostic-interface.html

Consists of two boards - CAN and ISO (there are no single-board). On a working device, all four LEDs are on.

In terms of repair, they mean the following:

ISO, CAN - the processor of the corresponding card counted the firmware from the flash, launched the 3.3v converter, thereby energizing the USB port controller AN2131 (AN2135), and Windows loaded the corresponding driver.

Battery - 12v from OBD

USB - 5v from USB

All other types of these boards can be considered "clones" of the original. Some are pretty much redesigned, but they are all RLT2002.

defined in the software as RLT2002 PROBE

In Windows Device Manager, you can see two devices

How to choose VVDI2 Commander Full,VVDI2 BMW,VVDI2 Basic?

VVDI2 can do like vvdi, such as BMW, Porsche.And VVDI2 covers functions of VVDI, VVDI 5th IMMO Adapter, BMW Multi Tool, CAS Plus, CAS4 Adapter, Tango, J2534.XhorseVVDI.com is original Xhorse authorized supplier,sell VVDI2 Full,VVDI2 BMW,VVDI2 Basic,and VVDI2 authorization.But how to choose these VVDI2 commander?

1.VVDI2 Key Programmer Comparsion:

Item number

VVDI2 Full version

Basic+VAG(SV86-B)

Basic(SV86-C)
Stops producing

Basic+BMW(SV86-D)

Price

2299USD

1550USD

499USD

1079USD

Basic Functions

√

√

√

√

VW

√

√

ｘ

ｘ

BMW

√

ｘ

ｘ

√

Porsche

√

√

ｘ

ｘ

5th AUDI Authorization

√

√

+320USD (SV86-2)

ｘ

BMW OBD Authorization

√

+720USD (SV86-3)

+720USD (SV86-3)

√

BMW CAS4 + Authorization

√

+260USD (SV86-4)

+260USD (SV86-4)

+260USD (SV86-4)

2.How to Choose the suitable VVDI2?

Please confirm the function you want to do and the car brands.If you need BMW key programmer,suggest you buy VVDI2 BMW,it can support BMW and J2534 protocol cars.

And VVDI2 basic version now is stop producing.

If you buy VVDI BMW,it support BMW CAS1-4 just like V7.7 BMW MULTI TOOL,but for BMW CAS4+,you need pay for the authorization fee about 260USD,then you can do CAS4.

https://blog.xhorsevvdi.com/how-to-choose-vvdi2-commander-fullvvdi2-bmwvvdi2-basic/

Xhorse vvdi tools

1.Xhorsevvdi is the authorized online Xhorse supplier.
2.Xhorsevvdi sells all of our tools with factory directly price, fast shipping.


CAR FANS C800 car list

CAR FANS C800 car list,detail you need to download excel:

https://www.chinacardiags.com/upload/pro/c800-car-coverage-list-en.xlsx

★Wide Vehicle Coverage: CAR FANS C800 support 35 Heavy duty brand, 21 BUS Brand, 16 Passenger car Brand, 32 Machinary vehicle brand and 46 ECU System, almost cover all brand heavy duty vehicles in market

★Powerful function of software: C800 is fully optimized based on the OEM scanner, which enhances the comprehensive diagnostic capability of the diesel vehicle. Some of the functions are based on the advanced technology accumulated by the R & D team for many years. The main diagnostic functions include reading the version information, reading/clearing the fault code, actual values, actuators, advanced function

★Fashionable design of hardware: 7 inch 800 x 480 touch screen, super light main unit, is easy to hold and operate. ARM9 CPU with 4GB memory, the software operation is faster than similar tools

★Advance Functions: Adjustment/Settings、Function Test、Special function, calibration.

★Online Updating: Log in the official website (www.carfans.net.cn) download and install the C800 intelligent diagnostic device upgrade client software, the device SD card through the card reader plug in the computer USB interface to complete the device software upgrade.

Equipment through the OBD extension line and special diagnostic connector and vehicle diagnostic seat connection,

the device automatically boot and enter the main interface of automotive diagnostics.

（1）Menu display area, including: truck system, bus system, passenger vehicles, engineering machinery, expert and

system settings.

（2）Model brand selection area: each model can be detected for all models brand.

CAR FANS C800 diesel Diagnostic system:

ECU

Update Date

BOSCH

2017/10/19

DENSO

2017/10/19

Delphi

2017/10/19

Perkins

2017/10/19

Dachai

2017/10/19

Weichai

2017/10/19

Yuchai

2017/10/19

Xichai

2017/10/19

Cummins

2017/10/19

Yunnei Power

2017/10/19

Changchai

2017/10/19

Shangchai

2017/10/19

Chaochai

2017/10/19

YANGCHAI

2017/10/19

QUANCHAI

2017/10/19

Doosan

2017/10/19

Electric unit pump

2017/10/19

XCE

2017/10/19

SCR

2017/10/19

FAW Sihuan

2017/10/19

Sida Power

2017/10/19

Huayuan Laidong

2017/10/19

FAW JIEFANG

2017/10/19

DONGFENG

2017/10/19

Mercedes-Benz

2017/10/19

CNHTC

2017/10/19

FOTON

2017/10/19

SANY

2017/10/19

JAC

2017/10/19

SFH

2017/10/19

CAMC

2017/10/19

UD

2017/10/19

VOLVO

2017/10/19

FUSO

2017/10/19

NAVECO

2017/10/19

MAN

2017/10/19

SCANIA

2017/10/19

JMC

2017/10/19

HINO

2017/10/19

ISUZU

2017/10/19

ShanQi Heavy Truck

2017/10/19

C&C Trucks

2017/10/19

QinLing

2017/10/19

HYUNDAI

2017/10/19

XGMA

2017/10/19

BEIBEN TRUCK

2017/10/19

KIA

2017/10/19

KingLong

2017/10/19

YUTONG

2017/10/19

HIGER

2017/10/19

GOLDEN DRAGON

2017/10/19

YOUNGMAN

2017/10/19

BYD

2017/10/19

ANKAI

2017/10/19

DAEWOO

2017/10/19

XUGONG

2017/10/19

Zhong Tong Bus

2017/10/19

Huanghai Motor

2017/10/19

Wuzhoulong

2017/10/19

ShenLong

2017/10/19

Toyota

2017/10/19

ASIA STAR

2017/10/19

Mudan Bus

2017/10/19

CDW

2017/10/19

Dayun motor

2017/10/19

Jinbei

2017/10/19

KAMA

2017/10/19

LIFAN

2017/10/19

WAW

2017/10/19

T-KING

2017/10/19

Wuzheng

2017/10/19

HengTong bus

2017/10/19

YOUYI

2017/10/19

Shaolin

2017/10/19

Shang Rao

2017/10/19

Zonda

2017/10/19

CHANA

2017/10/19

Mercedes-Benz

2017/10/19

Land Rover

2017/10/19

HYUNDAI

2017/10/19

VW

2017/10/19

Zhonghua

2017/10/19

JMC

2017/10/19

Great Wall

2017/10/19

Zhengzhou NISSAN

2017/10/19

JAC

2017/10/19

ZX auto

2017/10/19

Dongfeng

2017/10/19

LEO PAARD

2017/10/19

Chery

2017/10/19

FUDI

2017/10/19

GONOW

2017/10/19

Huanghai Motor

2017/10/19

SsangYong

2017/10/19

Caterpillar

2017/10/19

KOMATSU

2017/10/19

VOLVO

2017/10/19

SANY

2017/10/19

LOVOL

2017/10/19

John Deere

2017/10/19

HITACH

2017/10/19

KOBELCO

2017/10/19

HYUNDAI

2017/10/19

ZOOMLION

2017/10/19

CASE

2017/10/19

LISHIDE

2017/10/19

DOOSAN

2017/10/19

SUMITOMO

2017/10/19

YUTONG

2017/10/19

BOBCAT

2017/10/19

SHANTUI

2017/10/19

LIUGONG

2017/10/19

IHI

2017/10/19

XUGONG

2017/10/19

Kubota

2017/10/19

TAKEUCHI

2017/10/19

XGMA

2017/10/19

ATLAS

2017/10/19

TEREX

2017/10/19

YUCHAIHI

2017/10/19

LONKING

2017/10/19

SUNWARD

2017/10/19

SEM

2017/10/19

Jonyang

2017/10/19

SHPENGPU

2017/10/19

YTO

2017/10/19

JAC

2017/10/19

XINYUAN

2017/10/19

DASIN

2017/10/19

HENGTE

2017/10/19

SANYUAN

2017/10/19

HuangHe

2017/10/19

SHUNTONG

2017/10/19

ZHONGYOU

2017/10/19

ECU Reprogram

2017/11/5

calibration

2017/10/19

post-processing system

2017/10/19

ABS

2017/10/19

EOBD

2017/10/19

Circuit diagram

2017/10/19

How to Solve Communication Loss Renault Can Clip Alliance VI (926573)

This is a issue and solution of Can Clip Renault Alliance VI (926573) communication loss.

I want to share the positive results of the improvements made.
The disease of the new series is frequent breaks in communication.
I have this kind of photo 1.

POSSIBLE REASON

RF INTERFERENCE DUE TO POOR HIGH-FREQUENCY ISOLATION IN THE 5 V SUPPLY CIRCUIT.

Analyzed and made sure that the problem is only in the CAN board.

• By replacing the boards with an ideally working Clip, it is confirmed that the defect is in the CAN board.
• The current consumption of the Clip is measured in different modes of the Kan Clip program. Measurements on the table - only 12v power is connected to the OBD2 connector of the Clip.
• The output voltages of the sources 12b, 5c, 3c are measured - they correspond and are stable in different modes.

Consumption currents

• After connecting = 140Ma
• At the request of VIN = 190Ma
• When scanning multisets = up to 190Ma
• In the monitoring mode = 140Ma
• In the sleep mode (one green LED flashes) = 90mA

And, that in the sample probe, that in the probe with the termination of the connection - the currents are the same !!

At the time of termination of the connection (ON Clip does not see Alliance VI)

• Current = 140mA - as in the monitoring mode.
• All RF voltages on quartz resonators are presentwithout any amplitude changes.
• All the voltages of the stabilized sources are normal.

In this case, the percentage of CAN of the board issues a command "the connection with the Alliance probe" was lost and, interestingly, the computer does not lose the probe !

This is evident in - System Properties-Device Manager - 1B-Alliance Vehicule Communication Interface !!!

To restore communication with the probe, you need to turn the power on and off on it and restart the Clip software. Some kind of chip is hanging ! It looks like a processor.

Revisions

The condenser is necessarily ceramic! For good shunting of high frequency interference.

Intensity of clippings Clip has significantly decreased!

In the course of several hours of work - two short-term connection breaks.

SOLUTION:

While made on KR142EN5A ,

it has Uout = 5V, Istab = 3A at Uin = 7.5-15V.

Important: 12v on the KREEN only directly, with the OBD, with internal wiring in the OBD cable clip.

And with the placement of KREEN on 3 wires - a field for everyone's creativity :) It is possible outside the aluminum casing - for lazy ones, it is possible with a plate-radiator, inside, on the board.

To whom- how convenient

PS

The network already had a similar solution with one significant difference, according to their version: " In the course of time, manufacturers from China began to replace certain elements with similar parameters, and the power of this source was not enough." The first symptom is falling off over USB. "

And the solution is to replace the DC-DC converter.

Boris's decision is fundamentally different, albeit similarly externally.

Comment from myself : I assume that "a strong RF pick-up from the PWM 5v CAN board to the nodes of the Clip schema" is a consequence, and the reason is that somewhere the track is not finished and which element instead of eg the earth "hangs" in the air, or is not sealed of that denomination (there are plenty of such cases).

Indirectly confirms this theory that a break in communication can be achieved by touching a pyat in the region of the shim on the back of the board.

The Chinese also "experiment" with the converter, but the cliffs have not gone anywhere ...

Src: https://sites.google.com/view/repairrenaultcanclip/%D0%BD%D0%B5%D0%B8%D1%81%D0%BF%D1%80%D0%B0%D0%B2%D0%BD%D0%BE%D1%81%D1%82%D0%B8/%D0%BF%D0%BE%D1%82%D0%B5%D1%80%D0%B8-%D1%81%D0%B2%D1%8F%D0%B7%D0%B8-3?authuser=0

How to use Condor XC-MINI Cut New VW HU162T(9/10cuts)?

Condor XC-MINI Add Key:HU162T,and here we will introduce instruction about how to use condor mini key cutting machine cut New VW HU162T(9/10cuts) key.

1. Start condor mini key cutting machine. Select "Cut by bitting" then select the key blank "HU162t-9"

2. Select "Key Decode" or enter 9 bittings directly, follow machine prompt to decode or cutting keys.

It shows Clamp M2 and position B.

3.After 9 bittings cut OK,back to "Select key type" select 3 cuts to decode or enter bittings for left/right sides.Follow machine prompt use side D,require an extra blank to tight the cutting key.

How to use Lexia 3 PP2000 Diagbox Citroen Peugeot diagnostic tool

Lexia 3 PP2000 User Manual:
Lexia-3 diagnostic scanner tool for Citroen and Peugeot
Peugeot diagnostic software download
How to install Lexia 3 Diagbox 7.76 PP2000
Lexia vs Diagbox vs Planet PP2000
How to use Lexia 3 Citroen
How to use Diagbox
How to use PP2000
How to change language in Lexia3 PP2000Diagbox v7.76
How to rework Lexia 3 PCB as Original
Lexia 3 PP2000 Diagbox FAQs
THE MOST IMPORTANT NOTE:
ALL for Lexia 3 CHINA CLONE!!
This LEXIA guide is used for educational purpose; no one but yourself hold responsibility of what you try, especially for free lexia 3 software download.
Lexia 3 Citroen Peugeot diagnostic tool:
Lexia 3 price: Lexia 3 China CLONE for $40-$100 (quality depends)Lexia 3 PCB:
There are many CLONED versions of Lexia diagnostic equipments with different PCB design, from good to bad.

Lexia 3Best Quality:Src: https://www.obd2diy.fr/wholesale/lexia-3-pp2000-citroen-peugeot-diagnostic-interface.html
Lexia 3 Good Quality:Lexia 3 Poor Quality:Lexia 3 packing list:
1pc x Main unit with extension OBD2 cable
1pc x Long 9pin to USB cable
1pc x Short 9pin to USB cable
1pc x OBD2 cable
1pc x Instruction for Installation and Activation DVD for PP2000Peugeot diagnostic software download:
- Diagbox 7.76 download: Tested!! Safe to use!!Tested by experts and users for millions of timesLexia3 Diagbox v7.76:
https://www.obd2diy.fr/wholesale/diagbox-v601-software-for-lexia-3-pp2000-peugeot-citroen-diagnostic-tool-1755.html
The tested Diagbox software is tested on Windows XP and Windows 7 operating system, runing with Chinese Lexia-3. - FreeDiagbox 8.01 to 8.35: Not reconfigured!!!!!!!!not tested by experts, so try on your risks because of unknown security.
Diagbox Full v8.01 ISO:
https://mega.nz/#!V092FQrJ!5Em-RhtO8XfdziSVLqwpqKKfPxV-b6n8XCHdhAQEgBI
AWRoot_v7_Conf+Ativation_v8.exe No password
https://mega.nz/#!4lkUUI7C!2Gqp4ma0frNc5cSdf12L86O3wIvJD3cLkZSq5Y5klOY
Diagbox updates working with Diagbox V8.01 based on v7.xx profile, Extraction Password: Simple Diagbox_updt_802_Simple.exe https://mega.nz/#!Zx8U3SIb!19OlA1UmOqQzqMdYb9KVf95h8QiIpFDwmg4hVIeSToY
Diagbox_updt_803-810_Simple.exe
https://mega.nz/#!skMmAYgB!ygpcYNuOeTU8z0K7aKKyHM7_Qe4xg0EMfSZfHBU5T4s
Diagbox_updt_811-814_Simple.exe
https://mega.nz/#!AtMQDB4L!YXytKXPhIyxeXu_j9PXDqTXw5ppqnCD2ud5qXD_W6oU
Diagbox_updt_815-817_Simple.exe
https://mega.nz/#!hhVUwSaD!qlseKqwftJF4eVRLG-h5bk3pJ3V2jcRLxKEN_MiuuuA
For those who wish to stay with (ISO 639-1) standard: Diagbox_updt_803-808_Simple.exe (7.72)
Password: Simple #808
https://mega.nz/#!Q0FEiY7K!xkU5PlkGOQv0sg9I1KHxw4yIgU0XwHguJaWSbz79xVU
And those who wish to continue further:Diagbox_updt_810_Simple.exe (7.74)
No Password
https://mega.nz/#!IsFQAZia!y5S_rGcjsY6fIjrL9VMGmFPSVYVwqBSzLhr8dJ9e8LY
Cache Contents Restorer
No password
https://mega.nz/#!M113GKgC!DqCt18QSX8Mz7onRoClrYXXtBo3JT1qPF0jgSUJEAEM
Diagbox v8.18.rar 44.2 MB
https://mega.nz/#!10tykRDa!8mYQzz1xRAdsOjJ0il0lHCEn3s7fy1TaYOiZLgPowC0
Diagbox v8.19.rar 37.1 MB
https://mega.nz/#!tgd0gJ5Z!4eds8Ggf1XyJzIAzWOv1mIoy4Rs-Jd-r8M39UxaJMgk
Diagbox v8.20.rar 51.2 MB
https://mega.nz/#!phdkWQoI!vWsOwODncPQAVWtDRbEIlJJObNao0Q1rPGf7wnJWQck
Diagbox8.21.rar 9.2 MB
https://mega.nz/#!olUlHb7D!3G49QG4iu3jRbLpqFnYxY5LPWTXDEOj_PzInr9m3EnM
Lexia Diagbox v8.22.rar 6.7 MB
https://mega.nz/#!84MUBZBR!B-6Od2busYfEVMiLOCLTVp4tUlQVSaGxpRSuxf9HQXs
Lexia 3 Diagbox v8.24.rar 39.7 MBhttps://mega.nz/#!AgdU2JBC!VWceOZ4wR4061VTPlyzkBxA6Hlngkgq1nnCqFlo3p2Q
Diagbox v8.25.rar 149.4 MB
https://mega.nz/#!Zl0WTaJT!VFdgdlJsiLTE-fO1spMysR-1slANo_5yYcC97dmWLuk
Lexia3 Diagbox v8.26.rar 98.8 MB
https://mega.nz/#!Rh8T1QAK!VJCk20ftM11uTsl6V577cI9bG-xfT_-xIhsGeNWh8N0
Diagbox v8.27.rar 94.2 MB
https://mega.nz/#!9td0jDTZ!KffOxByxGlgQ7UbAVim1ZgUv-BiT70KEDil3TAl3-LE
Diagbox v8.29.rar 38.8 MB
https://mega.nz/#!4x1RAKZR!RDhkz_JD7vT4IaOgRzf0UvTQ9g-co9EmCdyWLNgE1HQ
Diagbox v8.30.rar 56.8 MB
https://mega.nz/#!50ExkJxB!8CYY2kT5vBbqdtDGzU7F-EbqHaEmOcx9xAmq_2Kmwh8
PSA Diagbox v8.31.rar 46.9 MBhttps://mega.nz/#!0x0GVCQS!A2yB3FtSZ5bLtaPkAqUzfDDsjpjmCqXTwFzJfTwcICU
PSA Diagbox v8.rar 44.0 MB
https://mega.nz/#!EhMjmLKQ!kMTEEFUjQsZ_IsCCN2cC5V1VwPpTWlipz8IUdhNm72Q
PSA Lexia3 Diagbox v8.rar 13.3 MB
https://mega.nz/#!Y0sgjbBD!2_7Ykzi3jyW6DuWtaQnwU0A3Hs_GWcdMGUV0OStYoGM
PSA Diagbox v8.35.rar 18.5 MB
https://mega.nz/#!JwsmjLra!00NU1EyDK4s1aX_UVIqGgdeYXr3qRpxlRv5duWVDCHc
*CREDITS to all contributors!!!
How to install Diagbox 7.76 software on Windows 7/Windows XP:
https://youtu.be/wJJdj3Qspkk
How to install Diagbox software on Windows 10/Windows XP:
This procedure and the software provided are intended for personal, educational and experimental use to install Lexia3 Diagboxv8 on Windows XP or Win 10. Diyobd2 hold no responsibility for any illegal or improper usage. Carry out this procedure at your own risk.
Notice
- Links for Diagbox 8.01, Diagbox updates and "AWRoot_v7_Conf+Ativation_v8.exe" are in the attachment.
- Starting with an installed (32 bit) Windows XP Pro SP3, ".NET 3.5 SP1" (I had FireFox and 7Zip also installed).
- Download and Install "VC++ 2008 Redistributable Package", a copy is available here "C:\teleassistance\visualC\vcredist_x86.exe" after installing Diagbox.
- Diagbox installs without issues on VMware Workstation and Player, but the below preparation is needed for Diagbox 7.62+ and V8.xx.
Preparation for Installing Diagbox 8.01 on VirtualBox
- Having installed 32 bit Windows + VirtualBox Guest Additions + .NET 3.51 and VC++ 2008 Redistributable Package, you can use the Powershell command "Get-WMIObject win32_BIOS" or the "DMIdecode" tool to obtain BIOS information.
- Start an administrator's CMD and navigate to "C:\Program Files\Oracle\VirtualBox\", and execute the following command (Replacing "Your VM" with your Virtual Machine's name, and System Serial with your hardware's, like "CDN29326BH", any other code may also work):
C:\Program Files\Oracle\VirtualBox>VBoxManage setextradata "Your VM""VBoxInternal/Devices/pcbios/0/Config/DmiSystemSerial""System Serial"
Installing Diagbox 8.01
1- Install Diagbox 7.01 and run update 7.02 then install update 7.xx-7.57 (or any v7.45+ update that creates "C:\AWRoot\dtwr\cfg\Config.sys")
2- Restart the computer and rename "C:\AWRoot" to "C:\AWRoot7" (you may need to stop some Diagbox processes)
3- Run Diagbox 8.01 installation until it requests Activation. Close it and run the tool "AWRoot_v7_Conf+Ativation_v8.exe" it will inject the necessary files and copy the configuration from "C:\AWRoot7".
4- Run Diagbox, it should continue the installation successfully.
Done !, Restart Diagbox 8.01 (as Administrator) to confirm all is well. If you face an issue, run the activation tool again and/or review "version.ini" as below.
Installing Updates
1- Download and install "Diagbox_updt_802.ISO" update.
2- Download and install subsequent updates or Maitresox updates.
Versions
The order of the version lines and which is active in VERSION.INI is important for the running of the system. Diagbox will display 08.01 if set as shown below. But Lexia will NOT work with "version.ini" set to V08.xx active (xx is the version number depending on which update is applied).
[APPLICATION]
version=08.01
version=07.65
If Lexia is started with "version=08.xx" active, "APPDIAG.SYS" will be corrupted and it will need to be restored before Diagbox will work again. To operate Lexia (after starting Diagbox with 8.xx), edit "version.ini" and comment/save "version=08.xx" (by inserting ";" as shown below) BEFORE starting Lexia.
Setting "version.ini" to 07.xx (by removing or commenting "version=8.xx" permanently) will prompt Diagbox to report V 07.xx, but everything will work fine..
[APPLICATION]
;version=08.08
version=07.72
Updates
- Diagbox v7 and v8 install and run on all x86 including Windows 10 TH1, TH2, RS1 and RS2.
- Entering a System Serial for the Virtual Machine (as described above) resolves the "psaAagent.exe" and the missing tabs issue on VirtualBox.
- If you get "Error 2" after restarting Diagbox, try commenting "version=8.xx" in "version.ini" before restarting Diagbox again.
P.S. Diagbox has been running on Firmware 4.3.4 since 7.66/8.02.
Lexia vs Diagbox vs Planet PP2000:
Lexia: Citroen, Planet: Peugeot, Diagbox: Citroen & Peugeot
Lexia3 - hardware
Lexia - Software for Citroen
Planet- Software for Peugeot
Diagbox - Front end which contains variations of both of the above
Diagbox is the only one which is still updated.
The hardware is currently on Revision C.
Diagbox: newer, PP2000: quicker
PP2000 and Diagbox are roughly the same thing , Diagbox being the newer software ,
PP2000 is a quicker software but will become obsolete over the next few years as Peugeotwill stop using it this year ,
no point in getting PP2000 then having to change to Diagbox
Peugeot Planet: easier and faster
I have planet and also being a newbie installed planet then Diagbox they both worked fine though Diagbox was a lot slower (you have to start Diagbox then choose planet off the option list) so basically if its just for use on your own car then using planet on its own is easier and faster though if your going to attempt using the interface on other vehicles may as well install Diagbox with planet and Lexia
Lexia + PP200 = Diagbox
Lexia is for citreon
planet PP2000 is for Peugeot
put both programmes into one software = Diagbox
if your going to buy it you might asswell get Diagbox which most new interfaces come with anyway.
Both Lexia &PP2000 available within Diagbox
They are the same.... the discs supplied usually contain PP2000 and Diagbox on one disc (PP2000 is also available within the Diagbox installation), and Lexia for Citroens on the other. Lexia is also available within Diagbox.
So if you find an interface with rev C, the software discs will contain everything you need and more.
PP2000 on 32-bit, Diagbox on 64-bit
Planet will only run on 32-bit. Diagbox will run on 64-bit, but when you try to call Planet through Diagbox it will crash because it must have 32-bit.
What I do is install VMWare Player (free). Using that, create a virtual machine XP SP3 32-bit (you will need the disk and key). Then install Planet into that. Works well. Sounds very techy, but it is surprisingly easy, because VMWare is so well documented. When installing Planet, do not plug the Lexia interface in to the PC until prompted.
Planet &Diagbox are software Lexia cable required
The Lexia is the cable required to use the software. Only the cable.
To use the cable you will need software as well, Peugeot Planet and Diagbox are the 2 pieces of software to choose from.
Diagbox is much newer software that supports even the latest cars. However I prefer the interface of Peugeot Planet, much easier not to get lost in there.
Generally when you buy a Lexia software will be included on a disk. As to whether it is genuine or not, you should check with the seller before purchase.
How to use Lexia 3 Citroen:
Here, i will show how to use Lexia to get to the engine ECU of Citroen berlingo 2. you can also use this code to scan for fault codes or to read live data.

Select a vehicle: Citroen berlingo 2Select the diagnostic application: LEXIAWhen using LEXIA, the PRO number is 5 digits long;
When using PP2000, the PRO number is 4 digits long.
The codes can be found on the label on the door
Enter the vehicle infoGo to LEXIADiagnosis, then Global testThe global test scans all systems in the vehicle such as the BSI, ABS, Air bag, engine ECU.
Wait for a few minutes for the Global Test to complete
Do not interrupt the scan
InjectionDiesel engineRHY SIMENS SID8012.0 HDI 90 - BOSCH EDC15C2
2.0 HDI 90 - SIENMENS SID801
2.0 HDI 110 - BOSCH EDC15C2
2.0 HDI 136 - SIEMENS SID803
1.6 HDI up to 2010 - BOSCH EDC16
Switch off the ignition and switch it on againInitialisation of the diaglogue with the ECU, in progress...Warning: do not disconnect the injectors when the engine is running
This may damage the engineYou can read / erase fault codes and also view live dataNow, i will show you how to see the ECU configuration
This is only required if it has been lost or the ECU has been damaged
Configuration, then Manual configurationAfter configuration operation, switch off the ignition for 15 seconds
Start the engine
Switch on the ignition again for 15 seconds
(after the configuration operation, configure the calibration identification reference)To update the configuration, hit F1, then follow the prompts on the screen.
Done!
How to use Diagbox:

Diagboxv7.76 is the newer diagnostic software, compared with PP2000. It runs fast and is easy to use on laptops for Peugeot & Citroen, replacing Peugeot Planet & Citroen Lexia. And Diagbox also provides most dealer functions at a fraction of the price involved with hiring the system from Peugeot or Citroen dealers.
Software version:
Diagbox v7.76
Operating system:
Windows XP (runs well);
Virtual machine on Windows 7;
Windows 10 64 Bit (tested with Diagbox 7.65 by customers);
Diagbox 7.76 How to install:
Step 1 - Install DAEMON Tools Lite
Step 2 - Install Diagbox
Step 3 - Activate Diagbox
Step 4 - Update Diagbox to v7.57
Step 5 - Update Diagbox to v7.58
Step 6 - Update Diagbox to v7.62
Step 7 - Update Diagbox to v7.66
Step 8 - Update Diagbox to v7.74
Step 9 - Update Diagbox to v7.76
Step 10 - Run Diagbox 7.76 to diagnose Citroen XM
Diagbox Update:
you have to do the updates manually for Diagbox.
And when you update from V7.02 the file ''APPDIAG.SYS'' gets deleted.
So before update back up your ''APPDIAG.SYS'' file (In C:\AWRoot\bin\fi)

Cost Effective Diagnostics:
Don't be fooled into believing Diagbox needs a Toughbook to run, it doesn't. BBA provide high spec, durable laptops perfect for use with Diagbox, and just as important they save you considerable expense. Save even more money by adding the Diagbox to one of our other diagnostic packages, and run various diagnostics software on a single laptop. Our expert software engineers can put a package together to suit your exact diagnostic requirements.

Function list:
Diagbox is the quick and easy way to keep customers happy by offering functions below:
- Automatic vehicle recognition
- Auto scan complete vehicle or individual ECU modules
- DTC reading and removal
- Wide range of actuator tests
- Complete list of live data streaming for all main ECU's
- Recordable / playback of live data
- Programming and installation of most new ECU's
- Programming keys
- Setting / removing speed limiters
- DPF regeneration & fluid additive correction
- Any many more money making functions

Latest Models Covered

Diagbox is able to diagnose the latest Peugeot and Citroen models including; DS3, DS4, RCZ, & Tepee. We can also supply the additional cable required to communicate with Peugeot and Citroen light commercial vehicles such as the Boxer 3, Bipper, Jumper 3, and Nemo.
How to use PP2000 key programming:
Lexia 3 clone can do programming keys to Citroenand Peugeot. There is a way for programming keys with the clone.
I have a Lexia clone
and I've programmed keys to the Peugeot Boxer and Fiat Ducato (as Peugeot boxer or Citroen jumper).
and two keys to a Citroen berlingo 2013, also with the cloned unit
So, it worked like a dream.
Try at Lexia or Diagbox in module BSI.
Look carefully at BSI, you'll find this option. Yes Diagbox certainly give advice on this topic but I think PP2000 it should give advice. Unfortunately, I will not give you exact instructions because I do not remember.
You must have CODE CARD with PIN.
If you have security code(pin code) should not be a problem to do this, PP2000 displays it step by step. One more thing if you have new key but it is china copy you will not be able to sync central locking.
How to use PP2000 for key programming:
There are two codes, one code for physically cutting the key (8 characters I think), and one code for the transponder (4 characters)
You open upPP2000, go into Accessories I think, orNewEquipment, and select transponder key.
It then guides you through it, reprogramming each key to the car, step by step.
First it asks for the transponder code as above, then it asks how many keys there are for the car. Input the total number of keys you have for the car (including the new one), then it will take you through step by step, starting with your main key.
It only take a minute or so for each key.
NOTE: PSA-COM Bluetooth should be a better choice for PSA cars programming!

Name PSA-COM Bluetooth Lexia 3
Figure
Price €84.99 €75.00
Software SuperScan Lexia 3 v48
PP2000 v25
Diagbox v7.76
Operation system Windows XP, Windows 2000/Vista/7/8/8.1/10 or Linux and Mac OS/X (using Wine emulation) Windows XP
Update Download sw online Via CD
Language Arabic, Croatian, Czech, Danish, Dutch, English (US), Finnish, French, German, Greek, Hebrew, Hungarian, Italian, Polish, Portuguese (Brazilian), Romanian, Russian, Serbian (Cyrillic), Spanish, Turkish English, German, French, Japanese, Russian, Spanish, Portuguese, Swedish, Turkish, Dutch, Polish, Italian, Hungarian, Greek, Czech
Bluetooth Yes No
Protocols ISO15765, PSA2000, Bosch KW71 and PSA2
Obdii diagnosis Yes Yes
Actuator test Yes Yes
Key programming Yes Yes, key programming via PP2000 (need luck)
Programming
(Special functions) Yes, works good in special functions:
Service reset
DPF regeneration
EGR self-test
Airbag programming
Injector programming
Power Steering calibration
ECU replacement
Car configurations No
Vehicle

Support: most Citroen and Peugeot cars, Fiat Scudo/Ulysse, Lancia Zeta/Phedra

Not support:Peugeot Boxer/Bipper and Citroën Jumper/Nemo, Peugeot 4007 and Citroën C-Crosser

Citroen and Peugeot cars from 1995 to 2014, incl. Peugeot 307

Citroen:C1,C2,C3,C4,C6,C8, C-CROSSER,NEMO,BERLINGO,JUMPY,JUMPER,AX,SAXO,BX
Peugeot:from 1995 to 2012

So, PSA-COM diagnostic tool wins!It works perfect in Bluetooth connection, key programming and special functions
How to activate Peugeot Planet 2000 (PP2000) Lexia 3 Software:
Follow pics until the 2nd last one, then add your details on this page to your keygen on the last page ,this will produce a code ,cut and paste this to the box in the 2nd last pic.

MANUAL ACTIVATION ONLY.
Click F5 with your mouse or press F5 on the keyboard.

Select Activation/Deactivation.

Select Activation.

Check your customer code and correct it if it is not correct. Then confirm to start activation.

Two ways to activate PP2000:
1. by connecting to the Internet address:
https://www.wrs-actia.com/psa/ClientLogin
2. by calling the hotline of your meiga representative.
In both cases above, you will be asked for the following information:
Your RRDI code, check whether the following code is correct: 001
The number of the version of your software packages: PP2000-23.43
The identifier of your PC: 4026979752
The server request code: 24188
From this information, you will be given an activation code.
Enter the code and then confirm to complete the activation.

Done!
Lexia 3 PP2000 ECU Fault Code P0299 P1351 P1164 P2562:
The ECU faults are, loss of turbo boost under load and intermittent problems with starting. I've changed the glow plugs but not yet tested to see if the heater relay is working.
Checked my DPF load and it says 65% with last regen ~650km's ago. Additive levels are good.
Seems the turbo boost issue is something to do with the boost solenoid?
Once I get these issues sorted, I can de-fap it.
PS. I've sorted the clutch and brake switch issues.
the planet screenshots:

Solutions:
Cleared the codes and ran it up the dual carriageway to get the fault.
The clutch one is from turning the car off/on while moving when the cruise control was on.
Got the P2562 and a EGR one (p0490).
Car also did a regen recently and is currently at 5% load, atleast the system is working.

How to change language in Lexia3 PP2000Diagbox v7.76:
It's a customer share of changing language in Diagbox, Lexia and PP2000. The user has tested on v7.76 and v7.77, and this is how to do it:
Note:
This is for educational and experimental use, and I hold no responsibility for any improper usage or damage to your system..
For Diagbox 7.76 / 7.77:
1- Open the File Explorer and navigate to "C:\AWRoot\dtrd\trans\", find the file "Language.ini" and create a copy "Language.ini.org".
Open the file Language.ini and under [LANGUAGE], change "Current=en_GB" to "Current=fr_FR" and save (I commented the original and added the new line to change from English to French).
[LANGUAGE]
;Current=en_GB
Current=fr_FR
For Lexia 3:
2a- Navigate to "C:\APP\Lexia\EXE\" find the file "langue.ini" and create a copy "langue.ini.org".
Open the file "langue.ini" and under [DicoMap], change all "%LG%" to FR (I commented the original 4 lines and added changed 4 lines to activate French language).
[DicoMap]
;CITACT=..\Dico\CITACT%LG%.dbz,APV
;CITTT=..\Dico\CITTT%LG%.dbz,APV
;CITTV=..\Dico\CITTV%LG%.dbz,APV
;THESAU=..\Dico\THESAU%LG%.dbz,APV
CITACT=..\Dico\CITACTFR.dbz,APV
CITTT=..\Dico\CITTTFR.dbz,APV
CITTV=..\Dico\CITTVFR.dbz,APV
THESAU=..\Dico\THESAUFR.dbz,APV
2b- Navigate to "C:\APPLIC\LCTLEX3\", find the file "Dico.txt" and create a copy named "Dico.txt.org".
Open the file "Dico.txt" and change the line "Dico=THELEXGB.DBZ" to "Dico=THELEXFR.DBZ" to change Lexia language to French.
;Dico=THELEXGB.DBZ
Dico=THELEXFR.DBZ
For PP2000:
3- If you wish to change PP2000, Navigate to "C:\APP\OutilRep\exe\", find the file "Dico.txt" and create a copy named "Dico.txt.org". Open the file "Dico.txt" and change the line "Dico=THESAUFR.DBZ" to "Dico=THESAUGB.DBZ" to change to English,
;Dico=THESAUFR.DBZ
Dico=THESAUGB.DBZ
The language change is achieved by replacing the "**" in "Dico=THESAU**.DBZ" with 2 letters representing the language you want, you can choose any of the 20 available languages.
Please notice that English=GB, French=FR and German=AL (French naming not unicode).
There are other incidents of "en_GB" that I changed to "fr_FR" in my installation. But I think the above is enough to get you working, you can find them in the INI and few java files....
Language table added
You can also use the attached Country Codes table to change the codes in your system, example for English:
Codes for Diagbox (DBX) go into C:\AWroot\.... in (2 Chrs.) statements such as "LauncherEN.DBZ" or (5 Chrs.) statements such as "Current=en_GB"
Codes for Lexia / PP200 go into C:\APP\... in statements such as "Dico=thesauGB.dbz" (in file Dico.txt)...
Please notice that you can have Diagbox, Lexia and PP2000 eaxh working in a different language...
PP2000 Language fall back and font sizing
Also, for PP2000, the statement in C:\APP\OUTILREP\EXE\LANGUE.INI:
[BackUpDico]
BackUpThesau=\app\outilrep\Dico\thesauGB.dbz
will determine the language used in case you choose an unsupported language (or missing language files). In this case you may also add the statement Arial=10 (or any font size that you may prefer) like below.
[FontScale]
Arial=10
p.s. Simple trick, if you wish to play with the font size, change the statement in Dico.TXT "Dico=thesauGB.dbz" to "Dico=thesau.dbz", this will force the system to use the backup language of your choice with the Arial fonts you decided... I tried it for PP2000, and it works.
Lexia resizing and screen positioning
And since I am at it, you can also position and resize Lexia on the screen to your liking by navigation to:
C:\APP\Lexia\EXE\ and finding the file: "ecran.ini".. open it using notepad and under:
[GENERAL]
position_X =0
position_Y =0
largeur_ecran = 1024
hauteur_ecran = 748
I think it is self explanatory, the X and Y affect positioning on the screen (from top left), and the ones I cant read are the Width and Height in pixels...; Try position_X =200 and position_Y=100, largeur_ecran = 800 and hauteur_ecran = 600.
Enjoy the Multilingual version of Diagbox 7.xx and feel free to share this information with reference..

The issue with Language button in Diagbox v7.74+ is sorted (Photo below).

Exaggerated examples for demonstration purposes:
1: Lexia, editing ecran.ini values to:
[GENERAL]
position_X =256 for the first photo and 96 for the 2nd
position_Y =96 for the first photo and 32 for the 2nd
largeur_ecran = 800 for the first photo and 1200 for the 2nd
hauteur_ecran = 600 for the first photo and 700 for the 2nd
2: PP2000, editing the values:
Dico.txt --> Dico=THESAU**.DBZ
Langue.ini --> Arial=24

I have also attached a snapshot for PP2000 in Arabic and Hebrew... Both languages are RTL (Right To Left) scripting. Regrettably I don't have the DBZ and DU8 files for them

How to rework Lexia 3 PCB as Original:
a cheaper Lexia 3 CitroenPeugeot diagnostic tool (sp08-d) for only €52 and there are missing some chip, compared to the original one.
Cheap Lexia 3

Original Lexia 3

Communicated with the vendor, they say the cheap Lexia 3 is designed with this kind of board as what i got.
On original interface "those caps" are resitors (473) 47k - R5 and R6. Optocouplers seems to be HCPL-063N-000E and HCPL-0500-000E. Also the filter from USB input is ACM2012D-900-2P (TDK) - most of clones have not this USB filter (2 resistors of 0 ohms are used).
On relay pcb the round red component is a varistor and original is V18ZA40P (in most clones is blue and have not the same specifications as the red one).
On relay pcb there is another optocoupler ZJYS51R5-2PT-01 (TDK) on the edge area near relays used for VAN BUS.
Some pictures from an original XS EVOLUTION PCB revision C.

He tells me, there mainly are two kinds of Chinese Lexia3 from different factories. One cheaper but lack some chips, the other with full chips of high quality.
The good Lexia 3 should come with PCBs as follows:

It's item no.sp08-c:
https://www.obd2diy.fr/wholesale/lexia-3-pp2000-citroen-peugeot-diagnostic-interface.html
And it's very kind of the vendor that he tells me, even if the PCB is designed as above, there are some different similar clones, not all HQ.
This is the comparison he shows me:
The left: good ; the right: bad

Big thanks to obd2diy.fr, with lots of info to help me. Finally, i adapted his advice and decided to exchange the cheap Lexia 3 for a high-quality Lexia 3 (sp08-c) with a bit more money. It works like a charm now.
Lexia 3 PP2000 Diagbox FAQs:
Q1: when install Lexia-3 Diagbox software, error message reading "ERROR Lexia: error during installation of Lexia. You have to reactivate to restart the installation."

A1: Your computer system isn't compatible with the software; please use Windows XP operation system.

Q2: Does Lexia test the tire pressure?
A2: If your car has Tire pressure control unit, Lexia-3 can test the tire pressure.

Q3-1: after plug the USB cable to the Lexia-3 (item NO. SP08-C), the indicator lights flash and off, off and flash, not stable.
A3-1: Is the USB cable also connected with the car? Check whether the USB cable is not connected well with the computer.
Q3-2: yes, I do. I try on several cars, still does not work.
A3-2: try to use another USB cable, if it will not work either, contact us, maybe it needs to return to us for check.

Q4: Does Lexia-3 work with Peugeot 308?
A4: Yes, it does, but which year of your Peugeot 308? Lexia-3 PP2000works with Peugeot 308 from 1996 to 2008.

Q5: Can Lexia-3 (item NO: SP08-C) work with Peugeot Partner Tepee B9 2011 diesel car?
A5: this car model is included in the supported carlist, so far no users feedback this car is not supported.

Q6: is PPS compatible with Peugeot 307 HDI?
A6: PPS2000 work with Peugeot 307, but it is not compatible with Hybrid Diesel Peugeot only with the gasoline car.

Q7: Can Lexia-3 PP2000 (item NO. SP08-C) work with Peugeot 407 2005, after install the NEW DPF, can I reset DPF counter? After Eolys is full, can I reset Eolys counter?
A7: PP2000 supports Peugeot 407 2005, but the DPF and Eolys are truck or diesel car systems, we haven't tested it.

Q8: Would you please store the software Lexia3 PP2000 and Diagbox6.01 in one CD?
A8: No, they are not allowed to store in one CD, they have to be stored them in two different CD, otherwise the software installation will get errors.

Q9: During the installation of Lexia-3, I got ERROR reading "Failure of the activation (error 20)."

A9: we are so sorry; we used to store the Lexia3 PP2000 software and Diagbox v6.01 software in the same one CD, now they are separately stored into two different CD. Please download Diagbox V6.01 software at: https://www.obd2vip.com/download/Diagbox-v6.01-setup.zip and try to reinstall, if it does not work either, contact us we will ship you CD.

Q10: I install Diagbox software on Windows XP3, 32BIT, but it can't communicate with the car, besides, I install PPS software in another computer (Win XP, 32bit, SP3), I successfully active it, but can't communicate with the car either, what's the problem?
A10: Try to install Lexia3 software, if Lexia3 software can communicate with the car. So it suggests you didn't install Diagbox software properly, or your computer system is not compatible with Diagbox software, we will produce video tutorial on how to install Diagbox, please check it in the column "video".

Q11: It can do C5 cars?
A11: It is not stable for c5 cars, you'd better not choose this for c5.

Q12: It can be updated?
A12: It is updated by CD.

Q13: I have installed it on windows 7 system, but it can not work, what is the problem?
A13: It can only be installed on XP system; you need to change another computer with XP system.
Q14:1.Is there any new car models which new Lexia-3 software can do?
A14 : Yes, the Lexia-3 Citroen/Peugeot Diagnostic PP2000 adds some new cars as follows:
Peugeout Bipper
Peugeout Boxer III
Peugeout Boxer III minibus
Citroen Nemo
Citroen Jumper III
Citroen Jumper III minibus
Q15:I have installed it on windows 7 system, but it cannot work, what is the problem?
A15:It can only be installed on XP system; you need to change another computer with XP system.
Q16:When i register, i meet the problem "the activation code is not valid (error code 11)", what should i do?This is the error picture:

A16:For this problem, the reason is that your keygen information is wrong. Here is the
sp08-d hot of the keygen.
The number of the version information in the red frame is wrong, please change it to "Lexia-348", then you can register successfully.

Please tell me if anything here is incorrect; BIG THANKS!!
More information of Lexia 3 clone will be updated here...

How to Update Xhorse Condor XC-MINI Key Cutting Tool?
